SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor Programming manual Page 163

Programming manual
B–61803E–1/10
6. FUNCTIONS OF THE MACRO
EXECUTOR
PROGRAMMING
153
Series 16/18–B
ID No. Bit information Status of module mounted Display unit
8200 0
1
2
5
14” CRT screen module mounted
9” CRT screen module mounted
10” CRT screen module mounted
None
14” color CRT
9.5” color LCD
9” CRT
8.4” color LCD
7.2” color LCD
8201 0
1
2
4
5
7
8
9
9” CRT module mounted
9” color CRT module mounted
14” color CRT module mounted
LCD 14” color CRT module mounted
LCD 9” CRT module mounted
Not defined
LCD 14” CRT module mounted
LCD 9” color CRT module mounted
9” monochrome CRT
9” color CRT
14” color CRT
14” color LCD
7.2” monochrome CRT
8.4” color LCD
NOTE
IDs Nos.8201 to 8203 do not have bit information.
Series 16/18–C
ID No. Bit information Status of module mounted Display unit
8200 0
1
2
3
5
14” CRT screen module mounted
9” CRT screen module mounted
10” CRT screen module mounted
None
None
14” color CRT
9.5” color LCD
9” CRT monochrome
8.4” color LCD
7.2” LCD monochrome
8201 1
2
3
4
5
6
7
8
9
10
11
12
9” CRT module mounted
9” color CRT module mounted
14” color CRT module mounted
LCD 14” color CRT module mounted
LCD 9” CRT module mounted
VGA 14” CRT module mounted
Not defined
LCD 14” CRT module mounted
LCD 9” color CRT module mounted
VGA 9” color CRT module mounted
VGA 14” CRT module mounted
VGA 9” CRT module mounted
9” CRT monochrome
8.4” LCD color
14” CRT (color)
9.5” LCD (color)
7.2” LCD monochrome
9.5” LCD monochrome
8.4” LCD color
NOTE
IDs Nos.8201 to 8203 do not have bit information.
