(4) Cutting condition data screen for drilling tools
(a) High-speed tool
101 #L OUTER T0101 RN 0. 400 AC 95 AN 80 TW 20. 000
102 #R OUTER T0202 RN 0. 400 AC 95 AN 55 TW 20. 000
103 #L OUTER T0303 RN 0. 400 AC 95 AN 55 TW 20. 000
251 #L OUTER TH T0404 RN 0. 400 AN 60 TW 20. 000
252 #R OUTER TH T0505 RN 0. 400 AN 60 TW 20. 000
*** MACHINING CONDITION (DRILLING) ***
[#9990=x]
HI-SPD DRIL (S-DIA. MM~ MM)
MATERIAL FEED/REV. CUT SPD.
(MM/REV.) (M/MIN.)
<#9991=1> #9992 #9993
<#9991=2> #9992 #9993
<#9991=3> #9992 #9993
<#9991=4> #9992 #9993
<#9991=5> #9992 #9993
<#9991=6> #9992 #9993
<#9991=7> #9992 #9993
<#9991=8> #9992 #9993
SET FEEDRATE AMOUNT BY MAX. VALUE.
WORK
MATERL
MENU
RETRN
DRILL CENTER REAMER BORE
<DRILL>
D Workpiece material 1 to 8 : x=28
D Workpiece material 9 to 16 : x=179
D Workpiece material 17 to 24 : x=182
<CENTER>
D Workpiece material 1 to 8 : x=92
D Workpiece material 9 to 16 : x=185
D Workpiece material 17 to 24 : x=188
<REAMER>
D Workpiece material 1 to 8 : x=137
D Workpiece material 9 to 16 : x=140
D Workpiece material 17 to 24 : x=143
<BORE>
D Workpiece material 1 to 8 : x=146
D Workpiece material 9 to 16 : x=149
D Workpiece material 17 to 24 : x=152
NOTE
Workpiece materials 9 to 16 and 17 to 24 are available only when
99 tools can be registered.
Previous page
Next page
