G. DIFFERENCES BETWEEN
Series 0 AND Series 16/18/0i
(CONVERSION FROM FS0 TO FS16/18/0i)
B–61803E–1/10
APPENDIX
460
NOTE
1 For P-CODE variables, about 1.63 meter of part program
memory is consumed per 100 pieces of variables when part
program storage is 20 to 80m. The more P–CODE are
used, the more part program memory decreases.
Series 16/18-A (Part program storage memory:
Up to 80m)
Series 20 (Part program storage memory:Up to 80m)
Series 21-MB (Part program storage memory on the
D201 series:Up to 80m)
Series 21-TB (Contorl unit A)
The maximum no. of the usable P-CODE variables depends
on the capacity of the part program memory.
Part program storage memory 10 m:
Parameter on compiling No. 9037 = 6
Part program storage memory 20 m:
Parameter on compiling No. 9037 = 12
Part program storage memory 40 m:
Parameter on compiling No. 9037 = 25
Part program storage memory 80 m:
Parameter on compiling No. 9037 = 51
Part program storage memory 160 m - 1280 m:
Parameter on compiling No. 9037 = 60
When compilation paraneter No.9007#7 EXT1 = 1, the No.
of P-code variables is the above value minus 1.
2 The P–CODE variables still maintain their values after the
power is turned off.
3 Before executing the conversational macro with the
complied ROM module loaded, erase all the programs in the
part program storage memory once.
(Turn on the power while pushing key with the setting
(PWE = 1).)
With this operation all the conversational macro functions
will be initialized to be ”blank”.
Array type variables for P–CODE in conversational macro
#10000 – can be refered to in 2 to 3 dimentional array type.
(See 6.13 (1) )
DELETE
Compile parameter
9044 Number of extended P–CODE dedicated variables to be used
Sets the number of extended P-CODE dedicated variables to be used.
Twelve floating-point variables or 30 integer variables make a set.
Each set uses 0.21m of tape storage.
9044 = 819 or less for 160m tape storage
9044 = 1638 or less for 320m tape storage
9044 = 3276 or less for 640m tape storage (9002#3 = 0)
9044 = 2184 or less for 640m tape storage (9002#3 = 1)
9044 = 5461 or less for 1280m tape storage (9002#3 = 0)
9044 = 2184 or less for 1280m tape storage (9002#3 = 1)
