Q. FS16i/18i/21i–TA Super CAPi T Concerning
CAP Control Module and User’s Module
589
(1) The method of creating the CAP control module depends on G–Code
system used in order to program the user’s macro program. In case
used G–code system is different between the CAP control module and
the user’s module, you must not use the combination.
Used G–Code system to
program the user’s macro
A B C
The method of
> ?:\sctsetup <in> <out> f
The method of
making the CAP
> ?:\sctsetup <in> <out> /B f
control module
> ?:\sctsetup <in> <out> /C f
f : available
: not available
(2) The user’s macro program in the user’s module and the execution
macro program in the CAP control module, can be executed with
restriction on CNC set in G–code system different from G–code
system used by them. However, the absolute command and the
incremental command cannot be used in the user’s macro program.
CNC setting in
G–Code system
(PRM.No.3401#6 GSB)
(PRM.No.3401#7 GSC)
A B C
The method of
> ?:\sctsetup <in> <out> f *1 *1
The method of
making the CAP
> ?:\sctsetup <in> <out> /B *2 f f
control module
> ?:\sctsetup <in> <out> /C *2 f f
f : It is available without restriction
*1 : Address U, W, H, and V are not available.
*2 : G90 and G91 are not available. Besides, in case the CAP program
is executed, the condition of ”G90” is necessary. If the CAP
program is executed in the condition of ”G91”, it is not executed
normally.
(3) Correspondence to an any G–Code system is available on and after
the following series and edition.
Series : BH0L/BH1C/BH2C
Edition : 02
Series : BH0M/BH1D/BH2D
Edition : 01
Q.7
RESTRICTIONS
ABOUT G–CODE
SYSTEM
