APPENDIXO. FANUC Super CAPi T
516
NOTE
1 #107?? is P–code variable. The limits are #10700–#10742.
When P–code macro variables 4000 function is available,
the limits of variables are #14000–#14042.
And, when Complex lathe application is available, the limits
of variables for 2nd path are #10800–#10842 or #14100–
#14142.
2 In case setting data is #0, the corresponding address is not
output.
3 The data in variables of expanded P–code cannot be
rewritten. If they are rewritten, the system might not work
correctly.
Example)
O9030;
#10700=123; Data for the macro call by G/M–code
#10701=2; Data of address A
#10702=#0; Format about address A
#10703=110.5; Data of address B
#10704=0; Format about address B
:
:
P8; Command for NC program output
M99
%
Then, ”G123 A2. B110.5;” is output.
The following variable is added.
#20703 =1: Complex lathe application is available.
=0: Complex lathe application is not available.
#7 #6 #5 #4 #3 #2 #1 #0
Bit Number
9764 UPC
Bit 0 (TRS) 0 : Sub-programs are called from the ROM in the
transfer process.
UPC 1 : In the user’s macro program, the NC program is
output to the format of G–code macro call or
M–code macro call when ”P8” or ”P9” is
executed.
0 : The above function is not available, and NC
program is output to the format as the program is
executed.
<Related parameter: No.9773#3(TCD)>
O.2.3
Additional Variable
O.2.4
Parameters
Previous page
Next page
