1. Fanuc
  2. SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor

SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor Programming manual Page 351

Programming manual
B–61803E–1/10
APPENDIX
E. FANUC Super CAP T/CAP II T MACRO
COMPILER/EXECUTOR (Series 16/18)
and Super Capi T Macro Compiler/
EXECUTOR (Series 16i/18i/21iT)
341
D Calling Subprograms II (when bit 3 of parameter No.9771 is 1) <available on Ver.2 or later>
+ 0 Process number +30 Unused
+ 1 Unused +31 Unused
+ 2 System utilization area (∗3) +32 Data Z
+ 3 Machining type (∗4) +33 Sub program No.
+ 4 Unused +34 Unused
+ 5 Tool post (∗6) +35 Unused
+ 6 Execution cycle (∗7) +36 Unused
+ 7 Data A +37 Unused
+ 8 Data B +38 Unused
+ 9 Data C +39 Unused
+10 Data I +40 Unused
+11 Data J +41 Unused
+12 Data K +42 Unused
+13 Data D +43 Unused
+14 Data E +44 Unused
+15 Data F +45 Unused
+16 Data H +46 Unused
+17 Data M +47 Unused
+18 Data Q +48 Run hour
+19 Data R +49 Unused
+20 Data S +50 Unused
+21 Data T +51 Unused
+22 Data U +52 * First variable number for roughing
+23 Data V +53 * First variable number for finishing
+24 Data W +54 * First variable number for chamfering
+25 Data X +55 * First variable number of a figure block
+26 Data Y +56 * Unused
+27 Unused +57 * Use status flag (0: Not used, 1: Used)
+28 Unused +58 * First variable number of the preceding process
+29 Unused +59 * First variable number of the next process
F: Ver.2 or later, J: Ver.3 or later, (
*
?): See the note below.
NOTE
Some item names depend on the version.
* : System management area –
Avoid data writing by a user program.
If there are no processes corresponding to +52 to +59, or if the current
process corresponds to any of those processes, the area is set to null
or 0.
