E. FANUC Super CAP T/CAP II T MACRO
COMPILER/EXECUTOR (Series 16/18)
and Super Capi T Macro Compiler/
EXECUTOR (Series 16i/18i/21iT)
428
To perform animated simulation in the dynamic graphic function
(A02B-0121-J973), data such as the figures of blanks, the chuck,
tailstock, and tools are required to be sent using commands [G10
P90???...] in advance from the NC unit to the graphic section. A program
consisting of the commands [G10 P90??? ...] needs to be operated before
a machining program coded in the NC format operates to display its
animated simulation.
When the conversational programming function is used, the necessary
data is automatically sent to the graphic section.
When either the menu or the tool is changed, execute the program
consisting of the commands [G10 P90???...] to send the data to the
graphic section.
(1) Start point for animated simulation
Command format G10 P90000 X_Z_ ;
Specifies the coordinates of the start point.
NOTE
When commands are issued in the following order
animated simulation does not start, but the data is
registered in the graphic section: A registration command,
G10 P90051, G10 P90052, G10 P90053, G10 P90054, or
G10 P90055, this command, and the registration end
command G10 P90050
(2) Drawing a straight line
Command format G10 P90001 X_Z_ ;
Draws a straight line from the current position to the specified end
point.
NOTE
When commands are issued in the following order,
animated simulation does not start, but the data is
registered in the graphic section: A registration command,
G10 P90051, G10 P90052, G10 P90053, G10 P90054, or
G10 P90055, this command, and the registration end
command G10 P90050.
E.8
COMMAND USED IN
THE DYNAMIC
GRAPHIC FUNCTION
E.8.1
Outline
E.8.2
Description
