SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor Programming manual Page 439

Programming manual

Page of 612

/ 612

B–61803E–1/10

APPENDIX

E. FANUC Super CAP T/CAP II T MACRO

COMPILER/EXECUTOR (Series 16/18)

and Super Capi T Macro Compiler/

EXECUTOR (Series 16i/18i/21iT)

429

(3) Drawing an arc

Command format

G10 P90002 X_Z_I_K_ ; for drawing clockwise

G10 P90003 X_Z_I_K_ ; for drawing counterclockwise

Draws an arc around the specified center of the arc from the current

position to the specified end point.

X: X coordinate of the end point

Z : Z coordinate of the end point

I : X coordinate of the center of the arc

K: Z coordinate of the center of the arc

NOTE

When commands are issued in the following order,

animated simulation does not start, but the data is

registered in the graphic section: A registration command,

G10 P90051, G10 P90052, G10 P90053, G10 P90054, or

G10 P90055, this command, and the registration end

command G10 P90050.

(4) Filling

Command format G10 P90004 ;

Fills an area.

NOTE

The color command G10 P90006 specifies a color used for

filling an area and the start point command G10 P90001 for

animated simulation specifies the center of the area.

(5) Type of line

Command format G10 P90005 Q_ ;

Specifies the type of line.

Q=0 : Solid line

1 : Dotted line

2 : Line with alternate dots and long segments

3 : Line with alternate long segments and sets of two dots

4 : Deletion

NOTE

The length of each line is specified.

(6) Color

Command format G10 P90006 Q_ ;

Specifies the color.

Q=0 : Black 4 : Blue

1 : Red 5 : Pink

2 : Green 6 : Light blue

3 : Yellow 7 : White

(7) End of registration of the figures of tools, workpieces, the chuck, and

tailstock

Command format G10 P90050 ;

Be sure to specify this command when the figure data of tools,

workpieces, the chuck, and tailstock have been registered.
