E. FANUC Super CAP T/CAP II T MACRO
COMPILER/EXECUTOR (Series 16/18)
and Super Capi T Macro Compiler/
EXECUTOR (Series 16i/18i/21iT)
435
NOTE
3 When the Z-axes in the two coordinate systems have opposite directions as shown above, the
command can be used in FANUC Super CAP T/II T and Super CAPi T.
The signs of coordinates used in the command G10 P90201 are as follows:
For the Z coordinates:
Z (+/–A –+B –/+C +/–D) when the direction of the Z-axis is right/left
where,
A : Z coordinate of the rightmost point in the destination
B : Z coordinate of the rightmost point in the source
C : Z coordinate of the center point of the screen in the destination
D : Z coordinate of the center point of the screen in the source
The upper right point is not affected by the direction of the coordinate system.
For the X coordinates:
X (+/–A –/+B –/+C +/–D) when the direction of the X-axis is up/down
where,
A : X coordinate of the uppermost point in the destination
B : X coordinate of the uppermost point in the source
C : X coordinate of the center point of the screen in the destination
D : X coordinate of the center point of the screen in the source
When the X-axis is a horizontal axis and the Z-axis is a vertical axis, the same signs can be
used by interchanging the X- and Z-axes.
4 A user program cannot refer to the coordinates of the center point of the screen in FANUC Super
CAP T/II T and Super CAPi T.
(27)Switching the display mode
Command format G10 P90210 Q_ ;
Switches between the two-spindle and one-spindle display modes.
NOTE
Issuing this command changes the mode and initializes the
screen. This command is effective only for a lathe with two
spindles and two turrets.
