B–61803E–1/10
APPENDIX
E. FANUC Super CAP T/CAP II T MACRO
COMPILER/EXECUTOR (Series 16/18)
and Super Capi T Macro Compiler/
EXECUTOR (Series 16i/18i/21iT)
409
[Up to 99 tools registered: drilling]
Y-axis drilling PROC(01) AREA MACHN-2 HOLE-DIA TOOL-NO REV/MIN T-CODE
0 2 1 41 14 15 18
FEED/MIN DWELL PATTERN CUT-DPTH HOLE-PTN
16 40 4 30 69
[Up to 99 tools registered: reaming]
Y-axis drilling PROC(01) AREA MACHN-2 HOLE-DIA TOOL-NO REV/MIN T-CODE
0 2 1 41 14 15 18
FEED/MIN DWELL HOLE-PTN
16 40 69
D Y-axis tapping (TT, T two-spindle type)
Y-axis tapping PROC(01) AREA HEAD NOMINL-D PITCH TOOL-NO REV/MIN T-CODE
0 2 3 39 43 14 15 18
FEED/MIN DWELL HOLE-PTN
16 40 69
D Y-axis tapping (T one-spindle type)
Y-axis tapping PROC(01) AREA NOMINL-D PITCH TOOL-NO REV/MIN T-CODE
0 2 3943141518
FEED/MIN DWELL HOLE-PTN
16 40 69
D Y milling (TT, T two-spindle type)
[Machining area: End face]
Y milling PROC(01) AREA HEAD DEPTH GRV-DIA TOOL-NO REV/MIN T-CODE
0 2 3 59 48 14 15 18
FEEDRATE1 FEEDRATE2 ESCAPE-SZ SHIFT-DR
73 51 75 70
[Machining area: Side face]
Ymilling PROC(01) AREA HEAD DEPTH GRV-DIA TOOL-NO REV/MIN T-CODE
0 2 3 59 48 14 15 18
FEEDRATE1 FEEDRATE2 ESCAPE-SX SHIFT-DR
74 51 76 70
D Y milling (T one-spindle type)
[Machining area: End face]
Y milling PROC(01) AREA DEPTH GRV-DIA TOOL-NO REV/MIN T-CODE
0 2 5948141518
FEEDRATE1 FEEDRATE2 ESCAPE-SZ SHIFT-DR
73 51 75 70
[Machining area: Side face]
Ymilling PROC(01) AREA DEPTH GRV-DIA TOOL-NO REV/MIN T-CODE
0 2 5948141518
FEEDRATE1 FEEDRATE2 ESCAPE-SX SHIFT-DR
74 51 76 70
* For the T two-spindle type, UNIT is replaced with SPINDLE.
