2. MACRO COMPILER AND MACRO
EXECUTOR
PROGRAMMING
17
(8) When the Series 16/18–A receives data, the following data reception
state is displayed.
The transmitted data and its address are displayed.
Mapping is merely a term indicating how much RAM the created
P-CODE program and executor occupy.
A single asterisk (
*
) refers to 16K bytes when a 2MB RAM module
is installed and 8K bytes when a RAM module of 1MB or less is
installed.
D When a RAM module of 1MB or less is installed
MACRO COMPILER/EXECUTOR P–CODE LOADER
(I/O PARAMETERS) (DATA TRANSFER)
ADRxxxxxxH:xx
I/O CHANNEL = 0 (MAPPING – 1MB)
I/O UNIT = 0 *ā*ā*ā*ā* ___________
BAUDRATE =11 ________________
STOP BIT = 1 ________________
INPUT CODE = 1 ________________
________________
________________
________________
________________
D When a 2MB RAM module is installed
MACRO COMPILER/EXECUTOR P–CODE LOADER
(I/O PARAMETERS) (DATA TRANSFER)
ADRxxxxxxH:xx
I/O CHANNEL = 0 (MAPPING – 2MB)
I/O UNIT = 0 *ā*ā*ā*ā* ___________
BAUDRATE =11 ________________
STOP BIT = 1 ________________
INPUT CODE = 1 ________________
________________
________________
________________
________________
