1. Fanuc
  2. SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor

SERIES 0i/16/18/20/21 Macro Compiler/Macro Executor Programming manual Page 529

Programming manual
B–61803E–1/10
APPENDIX
O. FANUC Super CAPi T
519
<Initial set – 1>
+ 0 Work material +30 Finishing allowance X (*2)
+ 1 Work figure (1=Bar ,2=Rough Shape) +31 Finishing allowance Z (*2)
+ 2 Outside diameter D (Bar) +32 End face cutting allowanceE, CZ
+ 3 Inside diameter H (Bar) +33 T code T [ 1 ]
+ 4 Length L (Bar) +34 Work shift amount SZ [ 1 ]
+ 5 Unused +35 Chuck number C [ 1 ]
+ 6 Unused +36 Chuck barrier X [ 1 ]
+ 7 T code T [ 2 ] +37 Chuck barrier Z [ 1 ]
+ 8 Workpiece shift amount SZ [ 2 ] +38
+ 9 Chuck number C [ 2 ] +39
+10 Chuck barrier X [ 2 ] +40
+11 Chuck barrier Z [ 2 ] +41
+12 Product length PL +42
+13 Coolant (*1, 31) +43
+14 Trapezoidal groove figure editing flag (*22) +44 Unused
+15 Tail stock number [ 2 ] +45 Unused
+16 Tool change position X [ 1 ] +46 Unused
+17 Tool change position Z [ 1 ] +47 System utilization area (*3)
+18 Tool change position X [ 2 ] +48 Run hour
+19 Tool change position Z [ 2 ] +49 Common safety point outer diameter X
+20 Tail stock reference point Z [ 2 ] +50 Common safety point outer diameter Z
+21 Tail stock reference point Z [ 2 ] +51 Common safety point inner diameter X
+22 Face position +52 Common safety point inner diameter Z
+23 Program prepared data (y, m, d) +53 * Unused
+24 Program prepared data (time) +54 * Unused
+25 Program update (y, m, d) +55
* First variable number of the 2nd initial setting block
+26 Program update (time) +56 * Unused
+27 Common safety point X for drilling (turning) +57 * Use status flag (0: Unused, 1: Used)
+28 Common safety point Z for drilling (turning) +58 * Unused
+29 Maximum spindle speed +59 * First variable number of the next block
NOTE
The contents of the above list might be difference in series
and editions
* : System management area –
Avoid data writing by a user program
(*?) : See the note below.
[ ? ] : ?=1 :1st path ?=2 :2nd path
