G. DIFFERENCES BETWEEN
Series 0 AND Series 16/18/0i
(CONVERSION FROM FS0 TO FS16/18/0i)
B–61803E–1/10
APPENDIX
462
#7 #6 #5 #4 #3 #2 #1 #0
Executor
parameter
9000 NDP
#1 (NDP) 0 : Local and common variables for a P-CODE program are
not displayed.
1 : Local and common variables for a P-CODE program are
displayed.
(Press the OFFSET key several times.)
Enter the variable number and press soft key [NO-SEL] to select the
number of the variable to be displayed.
⇒ The values of the variables just before the screen is displayed are
displayed. Note that even if the value of a variable is changed after
the screen is displayed, the displayed value does not change.
⇒ In FS16, variables of numbers #10000 or larger can be displayed
using soft key [NO-SEL]. To display P-CODE dedicated variables
of numbers #10000 or larger in FS0, set the number of the first
variable to be displayed in parameter 9001. Twenty variables after
and including the set variable are displayed.
G.12
THE METHOD FOR
DISPLAYING P–CODE
VARIABLES #10000
OR LARGER HAS
BEEN CHANGED.
Previous page
Next page
