A. MACRO PROGRAM EXAMPLE
APPENDIX
195
00010 O0030 ; Character display test
00020 G202 P3 ; Screen clear
00030 #8502=0 ; Data input invalid
00040 #8505=0 ; Cursor display OFF
00050 #143=100 ;
00060 M98 P0011 ;
00070 N001 G243 X0 Y2 A1 B0 K200 ; Partial screen erase
00080 X0 Y2 (DISPLAY TEST) ;
00090 G243 X0 Y4 A1 B0 K200 ;
00100 #141=100 ;
00110 M98 P0031 ;
00120 X0 Y4 (FANUC 0 SERIES MACRO COMPILER) ;
00130 #141=300 ;
00140 M98 P0031 ;
00150 G243 X0 Y4 A1 B0 K200 ;
00160 #141=100 ;
00170 M98 P0031 ;
00180 G243 X0 Y4 A1 B0 K200 ;
00190 X0 Y4 (*3441 2438 493D 3C28 00C3 00BD 00C4*) ;
00200 #141=300 ;
00210 M98 P0031 ;
00220 G243 X0 Y4 A1 B0 K200 ;
00230 #141=100 ;
00240 M98 P0031 ;
00250 G243 X0 Y4 A1 B0 K200 ;
00260 X0 Y4 (INT.
CODE )(*2F40 2F48 2F79 2F53*) ;
00270 #141=300 ;
00280 M98 P0031 ;
00290 G243 X0 Y4 A1 B0 K200 ;
00300 #141=100 ;
00310 M98 P0031 ;
00320 X0 Y4 A3 B0 (3 MULTI) ;
00330 #141=300 ;
00340 M98 P0031;
00350 G243 X0 Y4 A1 B0 K200 ;
00360 #141=100 ;
00370 M98 P0031 ;
00380 M98 P0032 ; Blink test sub program
00390 #141=100 ;
00400 M98 P0031 ;
00410 G243 X0 Y4 A1 B0 K200 ;
00420 X0 Y4 (DATA DISPLAY TEST 1234.567) ;
00430 #100=1234.567 ;
00440 G243 X0 Y6 F8.3 Z0 K200 ;
Soft key display
Timer
¾Enclose the characters to be displayed
with a parenthesis.
¾Enclose the internal code with “(*”
and “*)”.
