(b) Side cutter
(i) High-speed tool
WORK
MATERL
MENU
RETRN
101 #L OUTER T0101 RN 0. 400 AC 95 AN 80 TW 20. 000
102 #R OUTER T0202 RN 0. 400 AC 95 AN 55 TW 20. 000
103 #L OUTER T0303 RN 0. 400 AC 95 AN 55 TW 20. 000
251 #L OUTER TH T0404 RN 0. 400 AN 60 TW 20. 000
252 #R OUTER TH T0505 RN 0. 400 AN 60 TW 20. 000
*** MACHINING CONDITION (SIDECUT) ***
[#9990=x] ROUGHING [#9990=y] FINISHING
HI-SPD SIDECUT(S-WDTH MM~ MM) HI-SPD SIDECUT
MATERIAL FEED/REV. CUT SPD. MATERIAL FEED/REV. CUT SPD.
(MM/EDG.) (M/MIN.) (MM/EDG.) (M/MIN.)
<#9991=1> #9992 #9993 <#9991=1> #9992 #9993
<#9991=2> #9992 #9993 <#9991=2> #9992 #9993
<#9991=3> #9992 #9993 <#9991=3> #9992 #9993
<#9991=4> #9992 #9993 <#9991=4> #9992 #9993
<#9991=5> #9992 #9993 <#9991=5> #9992 #9993
<#9991=6> #9992 #9993 <#9991=6> #9992 #9993
<#9991=7> #9992 #9993 <#9991=7> #9992 #9993
<#9991=8> #9992 #9993 <#9991=8> #9992 #9993
SET FEEDRATE AMOUNT BY MAX. VALUE.
ENDMIL SIDCUT CHAMFR
D Workpiece material 1 to 8 : x=9009, y=9010
D Workpiece material 9 to 16 : x=9069, y=9070
D Workpiece material 17 to 24 : x=9075, y=9076
NOTE
Workpiece materials 9 to 16 and 17 to 24 are available only when
99 tools can be registered.
Previous page
Next page
