AC Spindle Motor Alpha Series Parameter manual Page 144

Parameter manual
B–65160E/02
2. FUNCTION EXPLANATION
FANUC AC SPINDLE MOTOR a series
135
1: The 1 rotation signal is detected each time the operating mode
changes.
16i/16015
Acceleration/deceleration time constant at spindle synchronization control
6532 3032 4032
6672 3172
1st–
2nd–
Data unit : 1 min
–1
/sec
(when parameter No. 4006#2 (SPDUNT) = 1, 10
min
–1
)
Data range : 0 to 32767
Standard setting : 0 (0 rpm/sec)
When the synchronization speed command at spindle synchronization
control is changed, set the acceleration/deceleration time constant.
When set data is 0, time constant does not function.
Set exactly the same data for 1st spindle and 2nd spindle.
16i/16015
Spindle synchronization speed arrival level
6533 3033 4033
6673 3173
1st–
2nd–
Data unit : 1 min
–1
(when parameter No. 4006#2 (SPDUNT) = 1, 10
min
–1
)
Data range : 0 to 32767
Standard setting : 10
For the synchronization speed command at spindle synchronization
control, if the deviations of the respective spindle motor speeds are
within the setting level, the spindle synchronization control complete
signal (FSPSY) becomes ”1”.
16i/16015
Shift amount at spindle phase synchronization control
6534 3034 4034
6674 3174
1st–
2nd–
Data unit : 1 pulse (360_/4096)
Data range : 0 to 4095
Standard setting : 0
Sets the shift amount from the reference point at spindle phase
synchronization control (1 rotation signal).
