AC Spindle Motor Alpha Series Parameter manual Page 409

Parameter manual
APPENDIX
C. TABLE OF PARAMETERS FOR
EACH MOTOR MODEL
B–65160E/02
400
Motor model name α0.5 α1 α1/15000 α2 α3 α3/12000
Applicable SPM SPM–2.2 SPM–2.2 SPM–2.2 SPM–5.5 SPM–5.5 SPM–5.5
Output specifications
Parameter No.
0.55/1.1 kW
3000/8000
min
–1
1.5/2.2 kW
3000/8000
min
–1
1.5/2.2 kW
3000/15000
min
–1
2.2/3.7 kW
1500/8000
min
–1
3.7/5.5 kW
1500/8000
min
–1
3.7/5.5 kW
1500/12000
min
–1
FS0 FS15 FS15i FS16i/16
6507 3007 3007 4007 00000000 00000000 ² 00000000 00000000 ²
6508 3008 3008 4008 00000000 00000000 ² 00000000 00000000 ²
6509 3009 3009 4009 00000000 00000000 ² 00000000 00000000 ²
6511 3011 3011 4011 00011000 00011001 ² 00011001 00011001 ²
6512 3012 3012 4012 10000010 10000000 ² 10000000 10000000 ²
6513 3013 3013 4013 00001110 00001110 ² 00001110 00001110 ²
6519 3019 3019 4019 00000100 00000100 ² 00000100 00000100 ²
6520 3020 3020 4020 8000 8000 15000 8000 8000 12000
6539 3039 3039 4039 0 0 ² 0 0 ²
6540 3040 3040 4040 2
6548 3048 3048 4048 2
6580 3080 3080 4080 83 70 ² 77
80*1
70 ²
6600 3100 3100 4100 3200 3100 ² 1550 1600 ²
6601 3101 3101 4101 95 100 ² 100 100 ²
6602 3102 3102 4102 6524 3557 ² 2567 1967 ²
6603 3103 3103 4103 0
40*1
0
87*1
²
²
0
68*1
0
75*1
²
²
6604 3104 3104 4104 1500 5540 ² 4100 4500 ²
6605 3105 3105 4105 0 0 ² 0 0 ²
6606 3106 3106 4106 3000 5540 ² 4100 4500 ²
6607 3107 3107 4107 0 0 ² 0 0 ²
6608 3108 3108 4108 0 0 ² 0 –2000 ²
6609 3109 3109 4109 25 25 ² 25 25 ²
6610 3110 3110 4110 1886 690 ² 474 475 ²
6611 3111 3111 4111 361 102 ² 175 200 ²
6612 3112 3112 4112 200 200 ² 200 19400 ²
6613 3113 3113 4113 1900 2100 ² 1192 1077 ²
6614 3114 3114 4114 0 17920 ² 0 0 ²
6615 3115 3115 4115 100 100 ² 100 100 ²
6616 3116 3116 4116 13842 10018 ² 9300 7950 ²
6617 3117 3117 4117 90 90 ² 90 28250 ²
6618 3118 3118 4118 100 100 ² 100 110 ²
6619 3119 3119 4119 5 5 ² 8 5 ²
6620 3120 3120 4120 0 0 ² 0 0 ²
6624 3124 3124 4124 0 0 ² 0 0 ²
6627 3127 3127 4127 240 176 ² 202 178 ²
6628 3128 3128 4128 0 0 ² 90 0 ²
6629 3129 3129 4129 0 0 ² 0 0 ²
6630 3130 3130 4130 25700 25700 ² 25700 25700 ²
6933 3313 3169 4169 0 0 ² 0 0 ²
Maximum output at acceleration (for
PSM selection)
2.5 kW
1.32 kW*1
2.87 kW
2.64 kW*1
²
²
6.4 kW
4.44 kW*1
7.9 kW
6.6 kW*1
²
²
*1 The maximum–acceleration output is the same as for conventional control.
