AC Spindle Motor Alpha Series Parameter manual Page 15

Parameter manual
FANUC AC SPINDLE MOTOR a series
1. ADJUSTMENT
B–65160E/02
6
(b) When there is no model code for which the parameter data is
similar, set model code 0 (or 64 when the speed range
switching function is used) for automatic parameter
initialization, then manually change the parameter data
according to the parameter list for each model.
Parameter No.
0 15
Settings
1st
spindle
2nd
spindle
1st
spindle
2nd
spindle
15i 16i/16
Settings
6633 6773 3133 3273 3133 4133 Model code
2. Set the relevant parameter to 1 to enable automatic spindle
parameter initialization.
Parameter No.
0 15
Settings
1st
spindle
2nd
spindle
1st
spindle
2nd
spindle
15i 16i/16
Settings
6519 #7 6659 #7 – – – 4019 #7 1
– – 5607 #0 5607 #1 5607 #0 – 0
NOTE
This bit is reset to its original value after automatic
parameter initialization.
3. Turn the CNC off, then on again. Then, the spindle parameters
specified with a model code are automatically initialized.
4. When no model code is available, manually change the parameter
data according to the parameter list for each model.
(3) Procedure for setting parameters for spindle HRV control
1. Set model code 0 (or 64 for models with the output switching
function) for automatic parameter setting. (To keep an adjusted
parameter unchanged, avoid carrying out automatic setting.)
2. Manually input the parameters, with reference to Appendix C,
”Motor Model–Specific Parameters.”
3. Set the detector–related parameters, according to the
configuration of the detector.
4. To make the spindle HRV control parameters effective, turn off
and on the CNC.
NOTE
The spindle HRV control parameters are valid with the
following spindle amplifiers and spindle software:
Spindle amplifier drawing number :
A06B–6102–Hxxx#H520
A06B–6104–Hxxx#H520
Spindle software series : 9D20
