3. EXPLANATION OF
PARAMETERS
FANUC AC SPINDLE MOTOR a series
179
PCMGOR:
Selects spindle orientation by a position coder and/or by a magnetic
sensor.
0: Selects only one type of spindle orientation (according to the
setting of bit 0 (PCMGSL) of parameter No. 4003.).
1: Selects both types of spindle orientation.
SLVEN: Specifies whether the slave operation function is used.
0: Not used.
1: Used.
SYCORI:
Specifies whether the orientation function is used during spindle
synchronization (9D00.D).
0: Not used.
1: Used.
16i/16 #7 #6 #5 #4 #3 #2 #1 #0015i15
SPDSW SPLDMT ORIENT
6515 3015 3015 4015
6655 3155
Standard setting: 0 0 0 0 0 0 0 0
ORIENT:
Presence of spindle orientation function (CNC software option)
0: Without spindle orientation function
1: With spindle orientation function
SPLDMT:
Specifies whether the spindle load monitor function is used (9D00.D).
(To use this function, the CNC software option is required.)
0: Not used.
1: used.
SPDSW: Presence of speed range switching function (CNC software option)
0: Without speed range switching function
1: With speed range switching function
16i/16 #7 #6 #5 #4 #3 #2 #1 #0015i15
RFCHK3 RFCHK2 RFCHK1 CMTVL FFSMTH
6516 3016 3016 4016
6656 3156 3156
Standard setting: 0 0 0 0 0 0 0 0
FFSMTH:
Presence of smoothing function on feedforward control
0: Without smoothing function
1: With smoothing function
Sets the presence of smoothing function on feedforward control of
servo mode (rigid tap, Spindle positioning etc.) and Cs contouring
control.
