AC Spindle Motor Alpha Series Parameter manual Page 382

Parameter manual
B–65160E/02
C. TABLE OF PARAMETERS FOR
EACH MOTOR MODEL
APPENDIX
373
Motor model name α3(IP55) α5 α5/12000 α8 α8/8000
Applicable amplifier SPM–5.5 SPM–11 SPM–11 SPM–11 SPM–11
Model code (applicable software) 105 (9D00/G) 106 (9D00/G) – 107(9D00/G) –
Output specifications
Parameter No.
2.2/5.5 kW
1500/6000
min
–1
5.5/7.5 kW
1500/8000
min
–1
5.5/7.5 kW
1500/12000
min
–1
7.5/11 kW
1500/6000
min
–1
7.5/11 kW
1500/6000
min
–1
FS0 FS15 FS15i FS16i/16
6507 3007 3007 4007 10000000 10000000 ² 10000000 ²
6508 3008 3008 4008 00000001 00000001 ² 00000001 ²
6509 3009 3009 4009 00000000 00000000 ² 00000000 ²
6511 3011 3011 4011 00001001 00001010 00001001* 00001010 ²
6512 3012 3012 4012 00000000 00000000 ² 00000000 ²
6513 3013 3013 4013 00011010 00011010 ² 00011010 ²
6519 3019 3019 4019 00001100 00001100 ² 00001100 ²
6520 3020 3020 4020 6000* 8000 12000* 6000 8000*
6539 3039 3039 4039 160 0 ² 0 ²
6580 3080 3080 4080 55 60 50* 65 ²
6600 3100 3100 4100 1550 1500 ² 1590 ²
6601 3101 3101 4101 100 100 ² 100 ²
6602 3102 3102 4102 1550 1730 ² 1590 ²
6603 3103 3103 4103 1450 1730 ² 1590 ²
6604 3104 3104 4104 1800 1500 ² 1500 ²
6605 3105 3105 4105 1800 1500 ² 1500 ²
6606 3106 3106 4106 1500 1500 ² 1500 ²
6607 3107 3107 4107 1500 1500 ² 1500 ²
6608 3108 3108 4108 300 300 ² 300 ²
6609 3109 3109 4109 10 10 ² 10 ²
6610 3110 3110 4110 475 629 ² 503 ²
6611 3111 3111 4111 20 17 ² 20 ²
6612 3112 3112 4112 1696 1000 ² 1000 ²
6613 3113 3113 4113 400 450 ² 400 ²
6614 3114 3114 4114 20 10 ² 20 ²
6615 3115 3115 4115 3 5 ² 5 ²
6616 3116 3116 4116 115 100 ² 100 ²
6617 3117 3117 4117 20 20 ² 20 ²
6618 3118 3118 4118 30 30 ² 30 ²
6619 3119 3119 4119 0 0 ² 0 ²
6620 3120 3120 4120 30 38 ² 40 ²
6624 3124 3124 4124 0 0 ² 0 ²
6627 3127 3127 4127 300* 164 ² 176 ²
6628 3128 3128 4128 0 7000 ² 0 ²
6629 3129 3129 4129 0 0 ² 0 ²
6630 3130 3130 4130 0 0 ² 0 ²
6933 3313 3169 4169 2700 0 ² 0 ²
