AC Spindle Motor Alpha Series Parameter manual Page 419

Parameter manual
Index
B–65160E/02
i–1
[A]
Acceleration/deceleration Time is Too Long, 260
Additional Description of Series 0, 119
Additional Description of Series 15, 125
Additional Explanations of Series 0–TC, 141
Additional Explanations of Series 0–TT, 143
Additional Explanations of Series 15–TT, 145
Additional Information on Parameters, 119
Adjusting the Orientation Stop Position Shift Parame-
ter, 56
Adjustment, 3, 245
Adjustment Procedure, 99
Alarm, 105
Alarm AL–02, AL–31 (Excessive Speed Deviation),
or AL–35 (Difference between the Inferred Speed
and the Motor Speed Obtained from the Position
Coder Signal Is Higher than the Set Level) Lights.
(Series 9D11/G or Later, and Series 9D12/A or Lat-
er), 262
Automatic Spindle Parameter Initialization, 5, 247
[B]
Built–in Spindle Motor α Series, 388
[C]
Calculating the Orientation Time, 57, 76
Calculating the Position Gain for Orientation, 55
Cs Contouring Control, 106
[D]
Deceleration Time is Too Long, 259
Detail of Parameter, 109, 148
Detail of Parameter for Position Coder System
Spindle Orientation., 46
Detail of Parameter for Rigid Tapping, 83
Details of Parameters, 61
Details of Parameters Related to Spindle Switching
Control, 157
Details of the Parameters Related to Spindle Differen-
tial Speed Control, 163
DI/DO Signals Related to Position Coder Method
Spindle Orientation, 43
DI/DO Signals Related to Spindle Switching Control,
153
DI/DO Signals Related to Spindle Synchronization,
131
Diagnosis, 104, 119, 141
Ditail of Parameter, 70
[E]
Explanation of Functions, 263
Explanation of Parameters, 165, 276
[F]
FANUC Series 16i/16, 362
For FANUC Series 0, 338
For FANUC Series 15, 346
For FANUC Series 15i, 354
Function Explanation, 41
[H]
High–speed Orientation, 59
[I]
Input Signals (PMC to CNC) for Second Spindle Con-
trol, 406
Input Signals (PMC to CNC) for Spindle Control, 404
[L]
LED Indicated a Status Error (Status Error Indication
Function), 261
List of Spindle Parameter Numbers, 337
Low Speed Range Parameters for Speed Range
Switching Control, 204
Low Speed Range Parameters for Sub Spindle Both
with Speed Range Switching Control and with
Spindle Switching Control, 232
[M]
Magnetic Sensor Method Spindle Orientation, 67
[N]
Number of Error Pulses in Spindle Synchronization,
139
