AC Spindle Motor Alpha Series Parameter manual Page 307

Parameter manual
FANUC AC SPINDLE MOTOR aC series
3. EXPLANATION OF
PARAMETERS
B–65160E/02
298
16i/16
15
15i
0
Leakage inductance compensation
6631 3131 3131 4131
6771 3271
16i/16
15
15i
0
Load meter data for output
6632 3132 3132 4132
6772 3272
16i/16
15
15i
0
Motor model code
6633 3133 3133 4133
6773 3273
Data unit : –
Data range : 220 or later
D If the motor model code is set to less than “219”, the
parameter miss setting alarm (AL–34) is occurred. Because
the parameter of ROM version 9D10 is not used at the ROM
version 9D12.
D Please perform the automatic parameter setting for 9D12 by
using the motor model code more than “220”.
Magnetic flux switching point used for calculating Acc/Dec time constant
on spindle synchronization control
6300 3480 3336 4336
6480 3700
16i/16
15
15i
0
Data unit : 1 min
–1
Data range : 0 to 32767
Standard setting : 0
In the area below the speed set in this parameter, acceleration/deceleration
is performed according to the time constant set in parameter No.4032
(Acceleration/Deceleration time constant on spindle synchronization
control (Series FS16)). In the area above the speed set in this parameter,
the time constant varies according to the torque characteristic. When “0”
is set in this parameter, the linear acceleration/deceleration is performed.
Please set the same value in this parameter for 1st spindle and 2nd spindle.
Bell type acceleration/deceleration time constant on spindle
synchronization (9D12 series only)
6304 3484 3340 4340
6484 3704
16i/16
15
15i
0
Data unit : msec
Data range : 0 to 512
Standard setting : 0
At the start and end of the linear acceleration/deceleration in spindle
synchronization control, this parameter is effective to reduce the
synchronization error. When “0” is set in this parameter, the linear
acceleration/deceleration is performed. Please set the same value in this
parameter for 1st spindle and 2nd spindle.
