B–65160E/02

C. TABLE OF PARAMETERS FOR

EACH MOTOR MODEL

APPENDIX

371

Motor model name α0.5 α1 α1/15000 α1 (IP55) α1.5 α1.5 (IP55)

Applicable amplifier SPM–2.2 SPM–2.2 SPM–2.2 SPM–2.2 SPM–5.5 SPM–5.5

Model code (applicable software) 100 (9D00/O) 101(9D00/G) – – 102 (9D00/G) –

Output specifications

Parameter No.

0.55/1.1 kW

3000/8000

min

–1

1.5/2.2 kW

3000/8000

min

–1

1.5/2.2 kW

3000/15000

min

–1

0.9/2.2kW

3000/8000

min

–1

1.1/3.7 kW

1500/8000

min

–1

0.9/3.7 kW

1500/8000

min

–1

FS0 FS15 FS15i FS16i/16

6507 3007 3007 4007 10000000 10000000 ² ² 10000000 ²

6508 3008 3008 4008 00000000 00000000 ² ² 00000000 ²

6509 3009 3009 4009 00000000 00000000 ² ² 00000000 ²

6511 3011 3011 4011 00001000 00001001 ² ² 00001001 ²

6512 3012 3012 4012 00000000 00000000 ² ² 00000000 ²

6513 3013 3013 4013 00011010 00011010 ² ² 00011010 ²

6519 3019 3019 4019 00001100 00001100 ² ² 00001100 ²

6520 3020 3020 4020 8000 8000 15000* 8000 8000 ²

6539 3039 3039 4039 0 0 ² ² 0 ²

6580 3080 3080 4080 100 60 ² ² 60 ²

6600 3100 3100 4100 3000 3000 ² ² 1500 ²

6601 3101 3101 4101 100 100 ² ² 100 ²

6602 3102 3102 4102 5500 3000 ² ² 2000 ²

6603 3103 3103 4103 5500 3000 ² ² 2000 ²

6604 3104 3104 4104 500 1500 ² ² 1500 ²

6605 3105 3105 4105 500 1500 ² ² 1500 ²

6606 3106 3106 4106 1500 1500 ² ² 1500 ²

6607 3107 3107 4107 1500 1500 ² ² 1500 ²

6608 3108 3108 4108 300 500 ² ² 500 ²

6609 3109 3109 4109 10 10 ² ² 10 ²

6610 3110 3110 4110 2155 629 ² ² 377 ²

6611 3111 3111 4111 26 8 ² ² 13 ²

6612 3112 3112 4112 652 652 ² ² 652 ²

6613 3113 3113 4113 1000 1550 ² ² 1600 ²

6614 3114 3114 4114 10 10 ² ² 10 ²

6615 3115 3115 4115 5 3 ² ² 2 ²

6616 3116 3116 4116 100 100 ² ² 100 ²

6617 3117 3117 4117 20 20 ² ² 20 ²

6618 3118 3118 4118 20 10 ² ² 10 ²

6619 3119 3119 4119 0 0 ² ² 0 ²

6620 3120 3120 4120 20 40 ² ² 40 ²

6624 3124 3124 4124 0 0 ² ² 0 ²

6627 3127 3127 4127 240 176 ² 293* 403 493*

6628 3128 3128 4128 0 0 ² ² 16000 ²

6629 3129 3129 4129 0 0 ² ² 0 ²

6630 3130 3130 4130 95 0 ² ² 0 ²

6933 3313 3169 4169 0 0 ² ² 0 ²

C.1

SPINDLE MOTOR α

Series
