AC Spindle Motor Alpha Series Parameter manual Page 160

Parameter manual

Page of 424

/ 424

B–65160E/02

2. FUNCTION EXPLANATION

FANUC AC SPINDLE MOTOR a series

151

16i/1601515i

Velocity loop integral gain on orientation (HIGH gear)

6550 3050 3050 4050

6690 3190

1st–

2nd–

Velocity loop integral gain on servo mode (HIGH gear)

6552 3052 3052 4052

6692 3192

1st–

2nd–

Velocity loop integral gain in Cs contouring control (HIGH gear)

6554 3054 3054 4054

6694 3194

1st–

2nd–

Position gain on orientation (HIGH gear)

6560 3060 3060 4060

6700 3200

1st–

2nd–

Position gain on servo mode (HIGH gear)

6565 3065 3065 4065

6705 3205

1st–

2nd–

Position gain in Cs contouring control (HIGH gear)

6569 3069 3069 4069

6709 3209

1st–

2nd–

(b) When the windings for low–speed power characteristics are

selected (CTH1A = 1, CTH2A = 1)

16i/1601515i

Velocity loop proportional gain on normal operation (LOW gear)

6541 3041 3041 4041

6681 3181

1st–

2nd–

Velocity loop proportional gain on orientation (LOW gear)

6543 3043 3043 4043

6683 3183

1st–

2nd–

Velocity loop proportional gain on servo mode (LOW gear)

6545 3045 3045 4045

6685 3185

1st–

2nd–

Velocity loop proportional gain in Cs contouring control (LOW gear)

6547 3047 3047 4047

6687 3187

1st–

2nd–

Velocity loop integral gain on normal operation (LOW gear)

6549 3049 3049 4049

6689 3189

1st–

2nd–

Velocity loop integral gain on orientation (LOW gear)

6551 3051 3051 4051

6691 3191

1st–

2nd–

Velocity loop integral gain on servo mode (LOW gear)

6553 3053 3053 4053

6693 3193

1st–

2nd–

Velocity loop integral gain in Cs contouring control (LOW gear)

6555 3055 3055 4055

6695 3195

1st–

2nd–

Position gain on orientation (LOW gear)

6563 3063 3063 4063

6703 3203

1st–

2nd–

Position gain on servo mode (LOW gear)

6568 3068 3068 4068

6708 3208

1st–

2nd–

Position gain in Cs contouring control (LOW gear)

6572 3072 3072 4072

6712 3212

1st–

2nd–

(3) Notes

The gear/clutch signals (CTH1A, CTH2A) are also used to select

parameters for Series 15 rigid tapping, feed axis position gain in Cs

contouring control, the number of teeth of an arbitrary gear, time

constant, backlash, and so forth.
