AC Spindle Motor Alpha Series Parameter manual Page 145

Parameter manual
FANUC AC SPINDLE MOTOR a series
2. FUNCTION EXPLANATION
B–65160E/02
136
16i/16015
Spindle phase synchronization compensation data
6535 3035 4035
6675 3175
1st–
2nd–
Data unit : pulse/2 msec
Data range : 0 to 4095
Standard setting : 10
This parameter reduces speed fluctuations when aligning phase of
spindles in spindle phase synchronization control.
When this parameter is ”0”, since the phase alignment amount is only
issued once, the position deviation quickly becomes large, and there
are large speed changes on phase alignment.
It is possible to perform smooth phase alignments through issuing
separate commands for phase alignment amounts for the number of 2
msec pulses set in this parameter.
16i/16015
Velocity loop proportion gain on servo mode/on synchronization control
(HIGH gear) CTH1A=0
6544 3044 4044
6684 3184
1st–
2nd–
Velocity loop proportion gain on servo mode/on synchronization control
(LOW gear) CTH1A=1
6545 3045 4045
6685 3185
1st–
2nd–
Data unit :
Data range : 0 to 32767
Standard setting : 10
This sets velocity loop proportional gain in synchronization control. It
is selected HIGH when CTH1A=0 of input signal, and It is selected
LOW when CTH1A=1 of input signal.
16i/16015
Velocity loop integral gain on servo mode/on synchronization control
(HIGH gear) CTH1A=0
6552 3052 4052
6692 3192
1st–
2nd–
Velocity loop integral gain on servo mode/on synchronization control
(LOW gear) CTH1A=1
6553 3053 4053
6693 3193
1st–
2nd–
Data unit :
Data range : 0 to 32767
Standard setting : 10
This sets velocity loop integral gain in synchronization control. It is
selected HIGH when CTH1A=0 of input signal, and It is selected
LOW when CTH1A=1 of input signal.
