AC Spindle Motor Alpha Series Parameter manual Page 337

Parameter manual
APPENDIX
A. SPINDLE PARAMETER TABLE
B–65160E/02
328
FS0 Internal
data
number
F–xxx
Classi-
fica-
tion
Application
Contents
Standard
initial
setting
data
FS16i
/16
FS15i
FS15
1st
Spindle
Internal
data
number
F–xxx
Classi-
fica-
tion
SUB
low
speed
SUB
high
speed
MAIN
low
speed
MAIN
high
speed
Contents
Standard
initial
setting
data
FS16i
/16
FS15i
2nd
Spindle
1st
Spindle
2nd
Spindle
6173 6353 3353 3573 3209 4209 10 Proportional gain of ve-
locity loop during
orientation (LOW)
f f
B 191
6174 6354 3354 3574 3210 4210 10 Proportional gain of ve-
locity loop in servo
mode (HIGH)
f f
B 192
6175 6355 3355 3575 3211 4211 10 Proportional gain of ve-
locity loop in servo
mode (LOW)
f f
B 193
6176 6356 3356 3576 3212 4212 10 Integral gain of velocity
loop during normal op-
eration
f f
B 194
6177 6357 3357 3577 3213 4213 10 Integral gain of velocity
loop during orientation
f f
B 195
6178 6358 3358 3578 3214 4214 10 Integral gain of velocity
loop in servo mode
f f
B 196
6179 6359 3359 3579 3215 4215 0 197
6180 6360 3360 3580 3216 4216 100 Gear ratio (HIGH)
f f
B 198
6181 6361 3361 3581 3217 4217 100 Gear ratio (LOW)
f f
B 199
6182 6362 3362 3582 3218 4218 1000 Position gain during
orientation (HIGH)
f f
B 200
6183 6363 3363 3583 3219 4219 1000 Position gain during
orientation (LOW)
f f
B 201
6184 6364 3364 3584 3220 4220 100 Rate of change in posi-
tion gain upon comple-
tion of orientation
f f
B 202
6185 6365 3365 3585 3221 4221 1000 Position gain in servo
mode/during synchro-
nization control (HIGH)
f f
B 203
6186 6366 3366 3586 3222 4222 1000 Position gain in servo
mode/during synchro-
nization control (LOW)
f f
B 204
6187 6367 3367 3587 3223 4223 0 Grid shift in servo mode
f f
B 205
6188 6368 3368 3588 3224 4224 0 206
6189 6369 3369 3589 3225 4225 0 207
6190 6370 3370 3590 3226 4226 10 Level for orientation
completion signal
f f
B 208
6191 6371 3371 3591 3227 4227 33 Motor speed limit during
orientation
f f
B 209
6192 6372 3372 3592 3228 4228 0 Orientation stop posi-
tion shift
f f
B 210
6193 6373 3373 3593 3229 4229 Depends
on the
sensor
MS signal constant
f f
B 211
6194 6374 3374 3594 3230 4230 0 MS signal gain adjust-
ment
f f
B 212
6195 6375 3375 3595 3231 4231 Depends
on the
model
Regenerative power
limit
f
C 213
6196 6376 3376 3596 3232 4232 20 Delay time until motor
power is cut off
f f
B 214
6197 6377 3377 3597 3233 4233 10 Setting of acceleration/
deceleration time
f f
B 215
6198 6378 3378 3598 3234 4234 0 Spindle load monitor
observer gain 1 (SUB
side)
f f
B 216
6199 6379 3379 3599 3235 4235 0 Spindle load monitor
observer gain 2 (SUB
side)
f f
B 217
