AC Spindle Motor Alpha Series Parameter manual Page 387

Parameter manual
APPENDIX
C. TABLE OF PARAMETERS FOR
EACH MOTOR MODEL
B–65160E/02
378
Motor model name αP22 αP22/8000 αP22 αP30 αP30
Applicable amplifier SPM–22 SPM–22 SPM–22 SPM–22 SPM–22
Model code (applicable software) 116 (9D00/G) – – 116 (9D00/G)
Output specifications
Parameter No.
11/15 kW
750/6000
min
–1
11/15 kW
750/8000
min
–1
7.5/11 kW
550/6000
min
–1
15/18.5 kW
575/4500
min
–1
15/18.5 kW
575/6000
min
–1
FS0 FS15 FS15i FS16i/16
6507 3007 3007 4007 10000000 ² ² 10000000 ²
6508 3008 3008 4008 00000000 ² ² 00000000 ²
6509 3009 3009 4009 00000000 ² ² 00000000 ²
6511 3011 3011 4011 00111010 ² ² 00111010 ²
6512 3012 3012 4012 00000000 ² ² 00000000 ²
6513 3013 3013 4013 00100110 ² ² 00100110 ²
6519 3019 3019 4019 00001100 ² ² 00001100 ²
6520 3020 3020 4020 6000 8000* 6000 4500 6000*
6539 3039 3039 4039 47 ² ² 0 ²
6580 3080 3080 4080 55 ² ² 50 ²
6600 3100 3100 4100 810 ² 600* 575 ²
6601 3101 3101 4101 100 ² ² 100 ²
6602 3102 3102 4102 1090 ² ² 650 ²
6603 3103 3103 4103 1090 ² ² 650 ²
6604 3104 3104 4104 1400 ² ² 2000 ²
6605 3105 3105 4105 1400 ² ² 2000 ²
6606 3106 3106 4106 1500 ² ² 1500 ²
6607 3107 3107 4107 1500 ² ² 1500 ²
6608 3108 3108 4108 300 ² ² 300 ²
6609 3109 3109 4109 10 ² ² 10 ²
6610 3110 3110 4110 914 ² ² 750 ²
6611 3111 3111 4111 30 ² ² 26 ²
6612 3112 3112 4112 500 ² ² 500 ²
6613 3113 3113 4113 130 ² ² 115 ²
6614 3114 3114 4114 12 ² ² 10 ²
6615 3115 3115 4115 5 ² ² 5 ²
6616 3116 3116 4116 100 ² ² 100 ²
6617 3117 3117 4117 20 ² ² 20 ²
6618 3118 3118 4118 30 ² ² 10 ²
6619 3119 3119 4119 0 ² ² 0 ²
6620 3120 3120 4120 30 ² ² 30 ²
6624 3124 3124 4124 0 ² ² 0 ²
6627 3127 3127 4127 164 ² 176* 148 ²
6628 3128 3128 4128 5500 ² ² 3000 ²
6629 3129 3129 4129 0 ² ² 0 ²
6630 3130 3130 4130 0 ² ² 0 ²
6933 3313 3169 4169 3600 ² ² 0 ²
