2. FUNCTION EXPLANATION
B–65160E/02
90
(c) In case of Series 15
In the rigid tapping, the same parameter address data is used for
the position gain of the tapping axis and the spindle.
Each position gain is selected as follows according to the gear
selection signal (CTH1A, CTH2A) .
Gear signal
CTH1A CTH2A
Parameter NO
0 0 3065
0 1 3066
1 0 3067
1 1 3068
(d) In case of Series 15i
Gear signal
CTH1A CTH2A
Parameter NO
0 0 3065
0 1 3066
1 0 3067
1 1 3068
(e) In case of Series 16i/16
The position gain parameter of the tapping axis in the rigid
tapping is selected as follows according to the gear selection
signal.
Standard machining: GR3O, GR2O, GR1O
Turning (T/TT series) and maching (M series) with surface
speed constant option: GR2, GR1
Second spindle of turning (T/TT series): GR21
(Multi–spindle control option is needed)
Standard machining [M series]
Gear signal
GR1O GR2O GR3O
Parameter NO
5280(*1)
1 0 0 5281
0 1 0 5282
0 0 1 5283
