AC Spindle Motor Alpha Series Parameter manual Page 187

Parameter manual
FANUC AC SPINDLE MOTOR a series
3. EXPLANATION OF
PARAMETERS
B–65160E/02
178
16i/16 #7 #6 #5 #4 #3 #2 #1 #0015i15
PWM3K DS5 DS4 DS3 DS2 DS1 ESED ESEC
6513 3013 3013 4013
6653 3153 3153
Standard setting: 0 X X X X X 1 0
X: Depends on the amplifier model.
ESEC: Setting of detection edge of position coder one rotation signal
0: CCW=Rising edge CW=Falling edge (Normally set to ”0”)
1: CCW, CW=Rising edge
ESED : Setting of detection edge of one rotation signal of position detection
signal in Cs contouring control
0: CCW=Rising edge CW=Falling edge
1: CCW, CW=Rising edge (Normally set to ”1”)
DS5-DS1:
Set the current dead band data.
PWM3K:
Setting PWM carrier frequency in low speed characteristic area of
speed range switching control
Determined depending on the motor model.
Normally, set to ”0”.
16i/16 #7 #6 #5 #4 #3 #2 #1 #0015i15
SYCORI SLVEN PCMGOR CHGSLT AXSLCT AXSUB AXISSL
6514 3014 3014 4014
6654 3154 3154
Standard setting: 0 0 0 0 0 0 0 0
AXISSL:Spindle switching function presence
0: Spindle switching function absent
1: Spindle switching function present
AXSUB: Presence of spindle switching function when SUB spindle is rotating
0: No spindle switching function when SUB spindle is rotating
1: Spindle switching function available when SUB spindle is rotating
AXSLCT:
Specifies whether to check the contacts of the main magnetic contactor
and sub-magnetic contactor for spindle switching
0: Makes a check by using the power line status check signal
(MCFN).
1: Checks the contacts of the main magnetic contactor and
sub-magnetic contactor.
CHGSLT: Specifies whether to check the contacts of the high and low magnetic
contractors for speed range switching
0: Makes a check by using the power line status check signal (RCH).
1: Checks the contacts of the high and low magnetic contactors.
