1. Fanuc
  2. AC Spindle Motor Alpha Series

AC Spindle Motor Alpha Series Parameter manual Page 351

Parameter manual
APPENDIX
B. LIST OF SPINDLE PARAMETER
NUMBERS
B–65160E/02
342
1st spindle
Contents
2nd spindle
Spindle switching
MAIN side
Contents
Spindle switching
SUB side
Spindle switching
MAIN side
Spindle switching
SUB side
High
–speed
charac-
teristics
Contents
Low
–speed
charac-
teristics
High
–speed
charac-
teristics
Low
–speed
charac-
teristics
High
–speed
charac-
teristics
Low
–speed
charac-
teristics
High
–speed
charac-
teristics
Low
–speed
charac-
teristics
6606 6907 6225 6255 6746 6947 6405 6435 Conventional : Integral gain of current
loop
HRV : Integral gain of current loop
6607 ° 6747 ° Conventional : Integral gain of current
loop (in Cs contour control mode)
HRV :
6608 6908 6226 6256 6748 6948 6406 6436 Conventional : Velocity at which the cur-
rent loop integral gain is zero
HRV : Velocity at which the current loop
integral gain is zero
6609 6909 6227 6257 6749 6949 6407 6437 Conventional : Velocity factor for propor-
tional gain of current loop
HRV : Filter time constant for processing
saturation related to the voltage command
6610 6910 6228 6258 6750 6950 6408 6438 Conventional : Current conversion
constant
HRV : Current conversion constant
6611 6911 6229 6259 6751 6951 6409 6439 Conventional : Secondary current factor
for activating current
HRV : Secondary current factor
6612 6912 6230 6260 6752 6952 6410 6440 Conventional : Expected–current constant
HRV : Criterion level for saturation related
to the voltage command/PWM command
clamp value
6613 6913 6231 6261 6753 6953 6411 6441 Conventional : Slip constant
HRV : Slip constant
6614 6914 6232 6262 6754 6954 6412 6442 Conventional : Compensation constant for
high–speed–rotation slip
HRV : Slip compensation coefficient for a
high–speed zone/slip compensation coef-
ficient at deceleration
6615 6915 6233 6263 6755 6955 6413 6443 Conventional : Compensation constant for
voltage applied to motor in dead zone
HRV : PWM command clamp value at de-
celeration
6616 6916 6234 6264 6756 6956 6414 6444 Conventional : Compensation constant for
electromotive force
HRV : Motor leakage constant
6617 6917 6235 6265 6757 6957 6415 6445 Conventional : Compensation constant for
phase of electromotive force
HRV : Regular–time voltage compensa-
tion coefficient for high–speed zone/regu-
lar–time motor voltage coefficient
Previous page
Next page
