1. Fanuc
  2. AC Spindle Motor Alpha Series

AC Spindle Motor Alpha Series Parameter manual Page 361

Parameter manual
APPENDIX
B. LIST OF SPINDLE PARAMETER
NUMBERS
B–65160E/02
352
1st spindle
Contents
2nd spindle
Spindle switching
MAIN side
Contents
Spindle switching
SUB side
Spindle switching
MAIN side
Spindle switching
SUB side
High
–speed
charac-
teristics
Contents
Low
–speed
charac-
teristics
High
–speed
charac-
teristics
Low
–speed
charac-
teristics
High
–speed
charac-
teristics
Low
–speed
charac-
teristics
High
–speed
charac-
teristics
Low
–speed
charac-
teristics
3307 ² 3527 ² Integral gain of velocity loop during cutting
feed in Cs contour control mode (LOW)
3313 ² 3493 ² 3533 ² 3713 ² Current overload alarm detection time
constant
3314 3312 3494 3492 3534 3532 3714 3712 Current overload alarm detection level
3315 ² 3387 ² 3535 ² 3607 ² Number of spindle gear teeth (HIGH)
3316 ² 3388 ² 3536 ² 3608 ² Number of position detector gear teeth
(HIGH)
3317 ² 3389 ² 3537 ² 3609 ² Number of spindle gear teeth (LOW)
3318 ² 3390 ² 3538 ² 3610 ² Number of position detector gear teeth
(LOW)
3391 3395 3396 3397 3611 3615 3616 3617 Time constant for spindle load monitor
magnetic flux compensation
3392 3425 3426 3427 3612 3645 3646 3647 Spindle load monitor torque constant
3393 ² 3378 ² 3613 ² 3598 ² Spindle load monitor observer gain 1
3394 ² 3379 ² 3614 ² 3599 ² Spindle load monitor observer gain 2
3456 ² 3460 ² 3676 ² 3680 ² Detection level 2 for completion signal for
orientation by position coder
3457 ² 3461 ² 3677 ² 3681 ² Detection level 1 for completion signal for
orientation by magnetic sensor
3458 ² 3462 ² 3678 ² 3682 ² Detection level 2 for completion signal for
orientation by magnetic sensor
3459 ² 3463 ² 3679 ² 3683 ² Stop position shift in orientation by mag-
netic sensor
3464 ² 3468 ² 3684 ² 3688 ² Motor deceleration time constant (HIGH)
3465 ² 3685 ² Motor deceleration time constant
(MEDIUM HIGH)
3466 ² 3686 ² Motor deceleration time constant
(MEDIUM LOW)
3467 ² 3469 ² 3687 ² 3689 ² Motor deceleration time constant (LOW)
3470 ² 3471 ² 3690 ² 3691 ² Speed at which deceleration time
constant limit starts (HIGH)
3474 ² 3475 ² 3694 ² 3695 ² Speed at which deceleration time
constant limit starts (LOW)
3472 ² 3473 ² 3692 ² 3693 ² Command multiplication for spindle
orientation by position coder
3478 ² 3479 ² 3698 ² 3699 ² Arbitrary number of velocity detector
pulses
3480 ² 3700 ² Magnetic flux switching point for calculat-
ing acceleration/deceleration time
constant during spindle synchronization
3481 ² 3482 ² 3701 ² 3702 ² Velocity loop gain speed compensation
factor
3483 ² ² ² 3703 ² ² ² Torque clamp level
