AC Spindle Motor Alpha Series Parameter manual Page 23

Parameter manual
FANUC AC SPINDLE MOTOR a series
1. ADJUSTMENT
B–65160E/02
14
(1) List of parameters for detectors
Parameter No.
0T 0M 15 15i 16i/16
Description
6500 #0 3000 #0 3000 #0
4000
#0
Direction of spindle and motor rotation
6511
#2, 1, 0
3011
#2, 1, 0
3011
#2, 1, 0
4011
#2, 1, 0
Motor speed detector setting
6503 #1 3003 #1 3003 #1
4003
#1
Whether to use a MZ sensor or BZ sensor
6504 #4 3004 #4 3004 #4
4004
#4
Type of a MZ sensor
6504 #1 3004 #1 3004 #1
4004
#1
Whether to use a BZ sensor mounted onto the spindle
6501 #2 3001 #2 3001 #2
4001
#2
Whether to use a position coder signal
6500 #2 3000 #2 3000 #2
4000
#2
Position coder mounting direction
6503
#7, 6, 5, 4
3003
#7, 6, 5, 4
3003
#7, 6, 5, 4
4003
#7, 6, 4
Position coder signal setting
0003
#7, 6
0028
#7, 6
5610
3706
#1, 0
Gear ratio between the spindle and position coder
(X1, X2, X4, X4, X8)
6501 #5 3001 #5 3001 #5
4001
#5
Whether to use a detector for Cs contouring control
6501 #6 3001 #6 3001 #6
4001
#6
Detector setting when the Cs contouring control function is
used with a built–in motor
6504 #0 3004 #0 3004 #0
4004
#0
Whether to use a high–resolution position coder
6501 #7 3001 #7 3001 #7
4001
#7
Mounting direction of detector for Cs contouring control
6507 #5 3007 #5 3007 #5
4007
#5
Whether to detect disconnection of signals from a detector for
Cs contouring control and a position coder
6556
to
6559
3056
to
3059
3056
to
3059
4056
to
4059
Spindle–to–motor gear ratio data
(This data is selected by spindle control input signals CTH1A
and CTH2A.)
6504 #2 3004 #2 3004 #2
4004
#2
Whether to use a reference switch signal
6504 #3 3004 #3 3004 #3
4004
#3
Setting of the detection edge of a reference switch signal
6518 #4 3018 #4 3018 #4
4018
#4
Whether to use a sensor Cs contour control function
1.2.4
Parameters Related to
Detectors
