1. Fanuc
  2. AC Spindle Motor Alpha Series

AC Spindle Motor Alpha Series Parameter manual Page 393

Parameter manual
APPENDIX
C. TABLE OF PARAMETERS FOR
EACH MOTOR MODEL
B–65160E/02
384
Motor model name αL26/10000αL22/10000αL15/10000
Applicable amplifier SPM–30SPM–22SPM–15
Model code (applicable software) –––
Output specifications
Parameter No.
Low speed
15/18.5 kW
500/2000 min
–1
High speed
9/11 kW
2000/10000
min
–1
Low speed
11/15 kW
500/2000 min
–1
High speed
18.5/22 kW
2000/10000
min
–1
Low speed
9/11 kW
500/2000 min
–1
High speed
15/18.5 kW
2000/10000
min
–1
FS0 FS15 FS15i FS16i/16
6630 3130 3130 4130 0 0 0
6902 3282 3138 4138 500 500 500
6903 3283 3139 4139 100 100 100
6904 3284 3140 4140 500 600 700
6905 3285 3141 4141 500 600 700
6906 3286 3142 4142 1800 1600 1500
6907 3287 3143 4143 1600 1500 1500
6908 3288 3144 4144 300 300 300
6909 3289 3145 4145 10 10 10
6910 3290 3146 4146 1331 1207 1331
6911 3291 3147 4147 45 40 40
6912 3292 3148 4148 333 800 200
6913 3293 3149 4149 160 200 180
6914 3294 3150 4150 0 13 0
6915 3295 3151 4151 2 5 5
6916 3296 3152 4152 100 100 100
6917 3297 3153 4153 20 20 20
6918 3298 3154 4154 30 20 10
6919 3299 3155 4155 0 0 0
6920 3300 3156 4156 0 0 0
6922 3302 3158 4158 0 1500 0
6923 3303 3159 4159 0 0 0
6925 3305 3161 4161 0 0 0
6930 3310 3166 4166 50 65 70
6933 3313 3169 4169 0 0 0
