AC Spindle Motor Alpha Series Parameter manual Page 69

Parameter manual
FANUC AC SPINDLE MOTOR a series
2. FUNCTION EXPLANATION
B–65160E/02
60
Parameter No.
0 15 15i 16i/16
Description
6515 #0 3015 #0 3015 #0 4015 #0 Spindle orientation function (Specify 1.)
0080
#3, 2
5609
#3, 2
5609 2 3702
#3, 2
Spindle orientation function of stop position external setting type
(#2: First spindle, #3: Second spindle)
6501 #2 3001 #2 3001 #2 4001 #2 Use of a position coder signal (Specify 1.)
6500 #2 3000 #2 3000 #2 4000 #2 Relationship between rotation directions of spindle and position coder
6500 #0 3000 #0 3000 #0 4000 #0 Relationship between rotation directions of spindle and motor
6503 #0 3003 #0 3003 #0 4003 #0 Choice of orientation method (Specify 0.)
6503
#3, 2
3003
#3, 2
3003
#3, 2
4003
#3, 2
Rotation direction on orientation
6503
#7, 6, 5, 4
3003
#7, 6, 5, 4
3003
#7, 6, 5, 4
4003
#7, 6, 5, 4
Setting of position coder signal
6517 #2 3017 #2 3017 #2 4017 #2 Position coder rotation signal detection function in normal rotation
6517 #7 3017 #7 3017 #7 4017 #7 Shortcut function for orientation specified from the stop state
6518#5 3018#5 3018#5 4018#5 Velocity command correction function in high–speed orientation
6518#6 3018#6 3018#6 4018#6 High–speed orientation function (Specify 1.)
6519#0 3019#0 3019#0 4019#0 Dead–zone compensation in Cs contouring control and orientation
(Specify 1.)
6531 3031 3031 4031 Orientation stop position
6538 3038 3038 4038 Highest orientation speed
6542
to
6543
3042
to
3043
3042
to
3043
4042
to
4043
Velocity loop proportional gain on orientation
6550
to
6551
3050
to
3051
3050
to
3051
4050
to
4051
Velocity loop integral gain on orientation
6556
to
6559
3056
to
3059
3056
to
3059
4056
to
4059
Gear ratio
6560
to
6563
3060
to
3063
3060
to
3063
4060
to
4063
Position gain on orientation
6564 3064 3064 4064 Deceleration time constant restriction ratio
6575 3075 3075 4075 Orientation completion signal detection level
6577 3077 3077 4077 Orientation stop position shift value
6584 3084 3084 4084 Motor voltage setting on orientation
6598 3098 3098 4098 Maximum speed of position coder signal detection
6284
to
6287
3464
to
3467
3320
to
3323
4320
to
4323
Motor deceleration time constant
6290
6294
3470
3474
3326
3330
4326
4330
Deceleration time constant restriction start velocity
6292 3472 3328 4328 Command multiplier for orientation
2.2.4
Details of Parameters
Previous page
Next page
