AC Spindle Motor Alpha Series Parameter manual Page 386

Parameter manual
B–65160E/02
C. TABLE OF PARAMETERS FOR
EACH MOTOR MODEL
APPENDIX
377
Motor model name αP15 αP15/8000 αP15 αP18 αP18/8000 αP18
Applicable amplifier SPM–15 SPM–15 SPM–15 SPM–15 SPM–15 SPM–15
Model code (applicable software) 114 (9D00/G) – – 115(9D00/G) –
Output specifications
Parameter No.
7.5/9 kW
750/6000
min
–1
7.5/9 kW
750/8000
min
–1
7.5/9 kW
750/6000
min
–1
3.7/5.5 kW
750/6000
min
–1
3.7/5.5kW
750/8000
min
–1
5.5/7.5 kW
500/6000
min
–1
FS0 FS15 FS15i FS16i/16
6507 3007 3007 4007 10000000 ² ² 10000000 ² ²
6508 3008 3008 4008 00000001 ² ² 00000000 ² ²
6509 3009 3009 4009 00000000 ² ² 00000000 ² ²
6511 3011 3011 4011 00111010 ² ² 00111010 ² ²
6512 3012 3012 4012 00000000 ² ² 00000000 ² ²
6513 3013 3013 4013 00011010 ² ² 00011010 ² ²
6519 3019 3019 4019 00001100 ² ² 00001100 ² ²
6520 3020 3020 4020 6000 8000* 6000 6000 8000* 6000
6539 3039 3039 4039 0 ² ² 0 ² ²
6580 3080 3080 4080 50 ² ² 65 ² ²
6600 3100 3100 4100 760 ² 510* 800 ² 530*
6601 3101 3101 4101 100 ² ² 100 ² 95*
6602 3102 3102 4102 1134 ² ² 1010 ² ²
6603 3103 3103 4103 1134 ² ² 1010 ² ²
6604 3104 3104 4104 2000 ² ² 2000 ² ²
6605 3105 3105 4105 2000 ² ² 2000 ² ²
6606 3106 3106 4106 1500 ² ² 1500 ² ²
6607 3107 3107 4107 1500 ² ² 1500 ² ²
6608 3108 3108 4108 500 ² ² 500 ² ²
6609 3109 3109 4109 10 ² ² 10 ² ²
6610 3110 3110 4110 984 ² ² 743 ² ²
6611 3111 3111 4111 28 ² ² 25 ² ²
6612 3112 3112 4112 533 ² ² 533 ² ²
6613 3113 3113 4113 140 ² ² 135 ² ²
6614 3114 3114 4114 12 ² ² 10 ² ²
6615 3115 3115 4115 7 ² ² 0 ² ²
6616 3116 3116 4116 100 ² ² 100 ² ²
6617 3117 3117 4117 20 ² ² 20 ² ²
6618 3118 3118 4118 30 ² ² 10 ² ²
6619 3119 3119 4119 0 ² ² 0 ² ²
6620 3120 3120 4120 40 ² ² 40 ² ²
6624 3124 3124 4124 0 ² ² 0 ² ²
6627 3127 3127 4127 144 ² 178* 147 ² 164*
6628 3128 3128 4128 6500 ² 0* 5500 ² 30000*
6629 3129 3129 4129 0 ² ² 0 ² ²
6630 3130 3130 4130 0 ² ² 0 ² ²
6933 3313 3169 4169 0 ² ² 0 ² ²
