AC Spindle Motor Alpha Series Parameter manual Page 403

Parameter manual
APPENDIX
C. TABLE OF PARAMETERS FOR
EACH MOTOR MODEL
B–65160E/02
394
Motor model name αB160M
–5.5/7000
αB160M
–11/6000
Parameter drawing No. L518 L536
Applicable amplifier SPM–30 SPM–45
Model code (applicable software) 173 (9D00/O) 178 (9D0A/A)
Output specifications
Parameter No.
Low speed
18.5/22 kW
350/1500 min
–1
High speed
22/25 kW
1300/8000 min
–1
Low speed
15/22 kW
290/650 min
–1
High speed
15/22 kW
650/4500 min
–1
FS0 FS15 FS15i FS16i/16
6507 3007 3007 4007 10000000 10000000
6508 3008 3008 4008 00000000 00000000
6509 3009 3009 4009 00000000 00000000
6511 3011 3011 4011 00001010* 10000010*
6512 3012 3012 4012 00000000 00000000
6513 3013 3013 4013 00100110 00111110
6519 3019 3019 4019 00001100 00001100
6520 3020 3020 4020 8000 4500
6523 3023 3023 4023 150* 144*
6539 3039 3039 4039 0 0
6580 3080 3080 4080 65 50
6600 3100 3100 4100 1500 1300
6601 3101 3101 4101 100 100
6602 3102 3102 4102 1500 1300
6603 3103 3103 4103 1500 1300
6604 3104 3104 4104 1200 1500
6605 3105 3105 4105 1200 1500
6606 3106 3106 4106 1500 1500
6607 3107 3107 4107 1500 1500
6608 3108 3108 4108 300 300
6609 3109 3109 4109 10 10
6610 3110 3110 4110 862 1212
6611 3111 3111 4111 21 38
6612 3112 3112 4112 417 370
6613 3113 3113 4113 100 150
6614 3114 3114 4114 10 10
6615 3115 3115 4115 5 5
6616 3116 3116 4116 100 100
6617 3117 3117 4117 20 20
6618 3118 3118 4118 10 10
6619 3119 3119 4119 0 0
6620 3120 3120 4120 50 80
6624 3124 3124 4124 0 0
6627 3127 3127 4127 136 176
6628 3128 3128 4128 0 0
6629 3129 3129 4129 0 0
6630 3130 3130 4130 0 0
6902 3282 3138 4138 500 450
