AC Spindle Motor Alpha Series Parameter manual Page 94

Parameter manual

Page of 424

/ 424

B–65160E/02

2. FUNCTION EXPLANATION

FANUC AC SPINDLE MOTOR a series

Standard machining [M series]

Gear signal

GR1O GR2O GR3O

Parameter NO

1 0 0 663

0 1 0 664

0 0 1 665

Turning [T/TT series] and maching [M series]

with surface speed constant

Gear selection signal

Fst. sp Snd. sp

Parameter NO

GR1 GR2 GR21 T/TT M

0 0 0 427 663

1 0 1 428 664

0 1 –– 429 665

1 1 –– 430 ––

D Set the gear teeth number of the position coder side.

Each parameter is selected according to the gear selection signal.

Standard machining: GR3O, GR2O, GR1O

Turning and maching with surface speed constant option: GR2,

GR1

Second spindle of turning: GR21

(Multi– spindle control option is needed)

Standard machining [M series]

Gear signal

GR1O GR2O GR3O

Parameter NO

1 0 0 666

0 1 0 667

0 0 1 668

Turning [T/TT series] and maching [M series]

with surface speed constant

Gear selection signal

Fst. sp Snd. sp

Parameter NO

GR1 GR2 GR21 T/TT M

0 0 0 431 666

1 0 1 432 667

0 1 –– 433 668

1 1 –– 434 ––
