AC Spindle Motor Alpha Series Parameter manual Page 235

Parameter manual
FANUC AC SPINDLE MOTOR a series
3. EXPLANATION OF
PARAMETERS
B–65160E/02
226
16i/1615 15i0
Spindle load monitor observer gain 1 (SUB side)
(9D00. D)
6198 3378 3234 4234
6378 3598
Data unit :
Data range : 0 to 32767
Standard setting : 500
16i/1615 15i0
Spindle load monitor observer gain 2 (SUB side)
(9D00. D)
6199 3379 3235 4235
6379 3599
Data unit :
Data range : 0 to 32767
Standard setting : 500
16i/1615 15i0
Motor voltage setting on normal rotation
6200 3380 3236 4236
6380 3600
Motor voltage setting on orientation
6201 3381 3237 4237
6381 3601
Motor voltage setting on servo mode
6202 3382 3238 4238
6382 3602
Data unit : 1%
Data range : 0 to 100
Standard setting : Depends on the motor mode.
When executing rigid tapping, Motor voltage setting on servo mode is
set to ”100” normally.
16i/1615 15i0
The reduction rate of position loop gain in returning to the reference
point on servo mode
6203 3383 3239 4239
6383 3603
Data unit : 1%
Data range : 0 to 100
Standard setting : 100 (100%)
This sets the reduction rate of position gain in returning to the
reference point in servo mode (rigid tap/spindle positioning etc.).
16i/1615 15i0
Feedforward coefficient
6204 3384 3240 4240
6384 3604
Data unit : 1%
Data range : 0 to 100 (0 to 100%)
Standard setting : 0
Set the feedforward coefficient when feedforward control is executed
in servo mode (rigid tap, spindle positioning).
