3. EXPLANATION OF
PARAMETERS
B–65160E/02
294
16i/16
15
15i
0
Spindle orientation deceleration constant (HIGH)
CTH1 = 0, CTH2 = 0
6592 3092 3092 4092
6732 3232
Spindle orientation deceleration constant (MEDIUM HIGH)
CTH1 = 0, CTH2 = 1
6593 3093 3093 4093
6733 3233
Spindle orientation deceleration constant (MEDIUM LOW)
CTH1 = 1, CTH2 = 0
6594 3094 3094 4094
6734 3234
Spindle orientation deceleration constant (LOW)
CTH1 = 1, CTH2 = 1
6595 3095 3095 4095
6735 3235
Data unit : –
Data range : 0 to 32767
Standard setting : 250
These parameters set the deceleration constant for the position coder
method spindle orientation. The value to be set can be calculated the
following formula.
Spindle orientation
deceleration constant
= 120 (Acc/Dec time constant) 0.8
Acc/Dec time constant (min
–1
/sec) is the setting data of PRM4069 to 4072
(Series 16).
16i/16
15
15i
0
Adjustment of SM terminal output voltage
6596 3096 3096 4096
6736 3236
Data unit : 0.1%
Data range : –1000 to +100
Standard setting : 0
This parameter is set when carrying out minute adjustment of SM terminal
output voltage. Output voltage becomes large in +data.
16i/16
15
15i
0
Delay time for motor excitation (9D12 series only)
6597 3097 3097 4097
6737 3237
Data unit : 1msec
Data range : 0 to 32767
Standard setting : 0
This parameter for setting time until motor excitation is stable in rigid
tapping.
