AC Spindle Motor Alpha Series Parameter manual Page 392

Parameter manual
B–65160E/02
C. TABLE OF PARAMETERS FOR
EACH MOTOR MODEL
APPENDIX
383
Motor model name αL15/10000 αL22/10000 αL26/10000
Applicable amplifier SPM–15 SPM–22 SPM–30
Model code (applicable software) – – –
Output specifications
Parameter No.
Low speed
9/11 kW
500/2000 min
–1
High speed
15/18.5 kW
2000/10000
min
–1
Low speed
11/15 kW
500/2000 min
–1
High speed
18.5/22 kW
2000/10000
min
–1
Low speed
15/18.5 kW
500/2000 min
–1
High speed
9/11 kW
2000/10000
min
–1
FS0 FS15 FS15i FS16i/16
6507 3007 3007 4007 10000000 10000000 10000000
6508 3008 3008 4008 00000001 00000001 00000000
6509 3009 3009 4009 00000000 00000000 00000000
6511 3011 3011 4011 00001010 00001010 00001010
6512 3012 3012 4012 00000000 00000000 00000000
6513 3013 3013 4013 00011010 00100110 00100110
6519 3019 3019 4019 00001100 00001100 00001100
6520 3020 3020 4020 10000 10000 10000
6523 3023 3023 4023 175 162 168
6539 3039 3039 4039 0 0 0
6580 3080 3080 4080 75 69 50
6600 3100 3100 4100 2000 2000 2000
6601 3101 3101 4101 90 100 100
6602 3102 3002 4002 2000 2000 2000
6603 3103 3003 4003 2000 2000 2000
6604 3104 3004 4004 800 800 500
6605 3105 3005 4005 800 800 500
6606 3106 3006 4006 1200 1500 1500
6607 3107 3007 4007 1200 1500 1500
6608 3108 3008 4008 300 300 300
6609 3109 3009 4009 10 10 10
6610 3110 3110 4110 539 862 855
6611 3111 3111 4111 16 28 19
6612 3112 3112 4112 333 500 333
6613 3113 3113 4113 160 130 180
6614 3114 3114 4114 0 14 15
6615 3115 3115 4115 5 5 5
6616 3116 3116 4116 100 100 100
6617 3117 3117 4117 20 20 20
6618 3118 3118 4118 30 30 50
6619 3119 3119 4119 0 0 0
6620 3120 3120 4120 30 35 50
6624 3124 3124 4124 0 0 0
6627 3127 3127 4127 147 164 148
6628 3128 3128 4128 10000 0 0
6629 3129 3129 4129 0 0 0
C.4
SPINDLE MOTOR α L
Series
