AC Spindle Motor Alpha Series Parameter manual Page 384

Parameter manual
B–65160E/02
C. TABLE OF PARAMETERS FOR
EACH MOTOR MODEL
APPENDIX
375
Motor model name α22 α22/8000 α30 α40 (0868) α40 (0861)
Applicable amplifier SPM–26 SPM–26 SPM–45 SPM–45 SPM–45
Model code (applicable software) 111 (9D00/G) – 125 (9D0A/A) 126 (9D0A/A) –
Output specifications
Parameter No.
2.2/5.5 kW
1500/6000
min
–1
5.5/7.5 kW
1500/8000
min
–1
5.5/7.5 kW
1500/12000
min
–1
7.5/11 kW
1500/6000
min
–1
7.5/11 kW
1500/6000
min
–1
FS0 FS15 FS15i FS16i/16
6507 3007 3007 4007 10000000 ² 10000000 10000000 10000000
6508 3008 3008 4008 00000001 ² 00000001 00000001 00000000
6509 3009 3009 4009 00000000 ² 00000000 00000000 00000000
6511 3011 3011 4011 00001010 ² 00001010 00001010 00001010
6512 3012 3012 4012 00000000 ² 00000000 00000000 00000000
6513 3013 3013 4013 00100110 ² 00111110 00111110 00111110
6519 3019 3019 4019 00001100 ² 00001100 00001100 00001100
6520 3020 3020 4020 6000 8000* 4500 6000 4500
6539 3039 3039 4039 0 ² 0 0 0
6580 3080 3080 4080 65 ² 60 65 50
6600 3100 3100 4100 1500 ² 1340 1600 1150
6601 3101 3101 4101 100 ² 90 90 100
6602 3102 3102 4102 1500 ² 1220 1450 1150
6603 3103 3103 4103 1500 ² 1220 1450 1150
6604 3104 3104 4104 1300 ² 1000 500 800
6605 3105 3105 4105 1300 ² 1000 500 800
6606 3106 3106 4106 1200 ² 2000 2000 2000
6607 3107 3107 4107 1200 ² 2000 2000 2000
6608 3108 3108 4108 300 ² 300 300 300
6609 3109 3109 4109 10 ² 10 10 10
6610 3110 3110 4110 924 ² 1223 826 1132
6611 3111 3111 4111 28 ² 38 31 33
6612 3112 3112 4112 333 ² 278 347 347
6613 3113 3113 4113 150 ² 95 100 130
6614 3114 3114 4114 15 ² 10 10 0
6615 3115 3115 4115 5 ² 5 5 0
6616 3116 3116 4116 100 ² 105 106 130
6617 3117 3117 4117 20 ² 20 20 30
6618 3118 3118 4118 30 ² 50 50 10
6619 3119 3119 4119 0 ² 0 0 0
6620 3120 3120 4120 50 ² 100 100 60
6624 3124 3124 4124 0 ² 0 0 0
6627 3127 3127 4127 142 ² 148 146 146
6628 3128 3128 4128 0 ² 0 0 0
6629 3129 3129 4129 0 ² 0 0 0
6630 3130 3130 4130 0 ² 0 0 0
6933 3313 3169 4169 0 ² 0 0 0
