AC Spindle Motor Alpha Series Parameter manual Page 30

Parameter manual
B–65160E/02
1. ADJUSTMENT
FANUC AC SPINDLE MOTOR a series
21
PCPL2, PCPL1, PCPL0, PCTYPE:
Set a position coder signal.
PCPL2 PCPL1 PCPL0 PCTYPE
MZ sensor,
BZ sensor
(Built–in
sensor)
High–resolution
magnetic
pulse coder
Others
0 0 0 0
256l/rev
(f103)
Magnetic drum
diameter
f65
Position
coder
High–resolu
tion position
coder
0 0 0 1
128l/rev
(f52)
–– ––
0 1 0 0
512l/rev
(f205)
f130 ––
0 1 0 1
64l/rev
(f26)
–– ––
1 0 0 0 –– f195 ––
1 1 0 0
384l/rev
(f154)
f97.5 ––
Set these bits to ”0000” when using a position coder or high–resolution
position coder. When a high–resolution magnetic pulse coder is being
used, these bits set the signal used for Cs contouring control. If the setting
of these bits is invalid, the one–rotation signal detection error alarm
(AL–39) occurs.
Motor model and Number of cogs of MZ sensor gear
Motor model Number of cogs of MZ sensor gear
α0.5 64 λ/rev
α1 to α3
(α6/12000)
128 λ/rev
α6 to α40
αP8 to αP60
256 λ/rev
16i/16 #7 #6 #5 #4 #3 #2 #1 #0015i15
BISGAN RFTYPE EXTRF SPDBIS HRPC
6504 3004 3004 4004
6644 3144
1st–
2nd–
HRPC: Specifies whether a high–resolution position coder is used.
0: Not used.
1: Used.
SPDBIS: Specifies whether a separate BZ sensor is used.
0: Not used.
1: Used.
Set this bit to 1 when a position coder signal is obtained by mounting a
BZ sensor onto the spindle without using a position coder. Set the type
of built–in sensor with PCPL2, PCPL1, PCPL0, and PCTYPE. Set this
bit to 0 when a built–in motor with a BZ sensor is used.
