AC Spindle Motor Alpha Series Parameter manual Page 213

Parameter manual
FANUC AC SPINDLE MOTOR a series
3. EXPLANATION OF
PARAMETERS
B–65160E/02
204
16i/1615 15i0
Motor voltage setting on normal rotation
6900 3280 3136 4136
6940 3500
Data unit : 1%
Data range : 0 to 100
Standard setting : Depends on the motor model.
16i/1615 15i0
Motor voltage setting on servo mode/on synchronization control
6901 3281 3137 4137
6941 3501
Data unit : 1%
Data range : 0 to 100
Standard setting : Depends on the motor model.
16i/1615 15i0
Base speed of motor power specifications
6902 3282 3138 4138
6942 3502
Base speed of motor power specifications
Conventional
HRV
16i/1615 15i0
Limit value for motor power specifications
6903 3283 3139 4139
6943 3503
Torgue limit value for motor power specifications
Conventional
HRV
16i/1615 15i0
Base speed
6904 3284 3140 4140
6944 3504
Activating voltage saturation speed at no–load
Conventional
HRV
16i/1615 15i0
Magnetic flux down start speed
6905 3285 3141 4141
6945 3505
Base speed limit ratio
Conventional
HRV
16i/1615 15i0
Current loop proportional gain data
6906 3286 3142 4142
6946 3506
Current loop proportional gain data
Conventional
HRV
16i/1615 15i0
3.2
LOW SPEED RANGE
PARAMETERS FOR
SPEED RANGE
SWITCHING
CONTROL
