1. Fanuc
  2. AC Spindle Motor Alpha Series

AC Spindle Motor Alpha Series Parameter manual Page 415

Parameter manual
APPENDIX
D. TABLE OF SIGNALS RELATED TO
SPINDLE CONTROL
B–65160E/02
406
16/16i 765432100TT
HEAD2
150
15i
MRDYB ORCMB SFRB SRVB CTH1B CTH2B TLMHB TLMLB
G233 G1433 G235 G074
RCHB RSLB INTGB SOCNB MCFNB SPSLB *ESPB ARSTB
G234 G1434 G234 G075
RCHHGBMFNHGB INCMDB OVRB DEFMDB NRROB ROTAB INDXB
G236 G1436 G236 G076
SORSLB MPOFB SLVB MORCMB
G236 G1436 G236 G077
SHB07 SHB06 SHB05 SHB04 SHB03 SHB02 SHB01 SHB00
G112 G1312 G239 G080
SHB11 SHB10 SHB09 SHB08
G113 G1313 G238 G081
M2R08I M2R07I M2R06I M2R05I M2R04I M2R03I M2R02I M2R01I
G106 G1306
M2SIND M2SSIN M2SGN M2R12I M2R11I M2R10I M2R09I
G107 G1307
M3R08I M3R07I M3R06I M3R05I M3R04I M3R03I M3R02I M3R01I
G108 G1308
M3SIND M3SSIN M3SGN M3R12I M3R11I M3R10I M3R09I
G109 G1309
R08I2 R07I2 R06I2 R05I2 R04I2 R03I2 R02I2 R01I2
G034
SIND2 SSIN2 SGN2 R12I2 R11I2 R10I2 R09I2
G035
R08I3 R07I3 R06I3 R05I3 R04I3 R03I3 R02I3 R01I3
G036
SIND3 SSIN3 SGN3 R12I3 R11I3 R10I3 R09I3
G037
RISGNB RIB12 RIB11 RIB10 RIB09 RIB08
G232 G233
RIB07 RIB06 RIB05 RIB04 RIB03 RIB02 RIB01 RIB00
G233 G232
D.2
INPUT SIGNALS
(PMC TO CNC) FOR
SECOND SPINDLE
CONTROL
