FANUC SUPER CAP T / CAP II T Operators manual Page 102

Operators manual
B–62444E–1/04
7. CHECKING MACHINING PROGRAMS
OPERATION
89
When offset data save restore function is effecive, the condition that is
able to start is limited. For understand easily, information of selecting
condition is displayed on the right of the screen.
*** PROGRAM MENU *** SIMU [CAP. HEAD– L]
Execution selection state
(1) Selection mode displaying.
It depends on the program selection screen whether offset data are
saved and restored or not. The state being selected now (selection
mode) is displayed by the character.
SIMU– – – – Processing simulation mode
(The offset data are saved and restored)
DRCT– – – – Direct operation of CAP program mode
(The offset data are not saved and restored)
CONV– – – –Convert into NC program
(The offset data are not saved and restored)
These selection mode are changed by pressing soft key in the main
menu 3 [Processing simulation] , 4 [Direct operation of CAP
program] 5 [Convert into CAP program] .
(2) Program selection state displaying
When offset data save and restore function is effective, it is
neccessary select the execute program. Whether the program is
selected in current is displaying by the reverse color.
Red
It isn’t selected the executing program in current selection mode.
Under this condition, it is impossible to start both Processing
simulation and machine drive. (it will be became P/S 3014
“program is not selected”) Please select the executing program in
current selection mode.
Green
Already selected the executing program in current selection mode.
It is possible to start program execution. However, under this
condition, only be able to start animation in Processing
simulation, and able to machine start in Dirrect operation CAP
program. If the executing program is selected in Processing
simulation mode, and start the direct drive, it will be became P/S
3014. Same way, if the executing program is selected in Direct
drive mode and start the animation, it will be became P/S 3014.
In Convert into NC program mode, it is possible to start both
animation and direct driving.
7.4.4
Execution Selection
State Display
