FANUC SUPER CAP T / CAP II T Operators manual Page 110

Operators manual
B–62444E–1/04
8. EDITING MACHINING PROGRAMS
OPERATION
97
A process can be deleted or added by pressing the [DELETE] or
[INSERT] soft key shown below.
< DELETE INSERT PRGRM
END
MCHN–C TOOL–D PLOTWINDOW
OFF
PROCES
EDIT
DETAIL
DATA
If the soft keys shown above are not displayed, press the rightmost [+] soft
key for several times.
NOTE
A process can be deleted or inserted only when the cursor
is positioned to a process data item. When the cursor is
positioned to figure data, figure data can be deleted or
inserted. None of the initial setting data can be deleted.
The processes contained in a machining program can be deleted in units
of processes.
Move the cursor to the process to be deleted, then press the [DELETE]
soft key. The message for confirming the operation and soft keys are
displayed as shown below.
CANCEL
EXEC
EXEC REALLY? YES:[EXEC] NO:[CANCEL]
[CANCEL] : Cancels the deletion and returns to the original state.
[EXEC] : Deletes the process.
To add a new process to a machining program, move the cursor to the
process which is to be followed by the new process and press the
[INSERT] soft key.
By performing this operation, the new process is created. Select a
machining type as when a program is created.
8.2
EDITING A
MACHINING
PROGRAM IN UNITS
OF PROCESSES
(PROGRAM SCREEN)
8.2.1
Deleting a Process
8.2.2
Adding a New Process
