8. EDITING MACHINING PROGRAMS
B–62444E–1/04
OPERATION
104
Adding rounding (R3)
< WINDOW
OFF
INSERT ALTER MCHN–C TOOL–D PLOTALTER
FIGURE
DELETE DETAIL
DATA
DIRECTION B= ¾
TAPER END X CORD. X=
TAPER END Z CORD. Z=
COMPONENTX I=
COMPONENT Z/ANGLE K/J=45.000
LENGTH Q=
ROUGHNESS(1–10) SR= 5
CONTR FORM(TAPER LINE)
PROC (01) AREA HEAD ROUGHNES TOOL–NO CUT–SPD FEED/REV T–CODE
BAR (F) OUTER ENDHEAD–L 5 102 80 0.25 0101
START X= 20.000 Z= 0.000
² X= 20.000 Z= 30.000
J¾ X= 77.172 Z= 58.58
° X= 10.000 Z= 60.000
SR=5
Move the cursor (J) to the figure which is to be followed by a new figure,
then
[INSERT]
Check that the graphic pattern menu is displayed on the soft key field, then
[ROUND]
Check that the input data items for rounding are displayed in the window
guidance, move the cursor to the radius of rounding, then
3
INPUT
[INSERT]
By performing the operation above, the contour after the new figure is
added is recomputed and the changed figure data is displayed on the
screen. The new figure is displayed on the same screen.
