The last key operation [FIGURE END] in 2.3.4 creates a new process,
resulting in the machining type menus being assigned to the soft keys as
shown below:
<
1
BAR
2
PT.RPT
3
RESID.
6
GROOVE
7
NECK
9
DRILL
10
TAP
4
FACING
5
THREAD
8
CENTER
Press the rightmost soft key [ + ] to display the soft keys for page 2 of
machining type menus shown below.
<
11
SINGL
12
AUX
13
C–CNTR
16
C–GROV
17
C–NOTC
19
TRANS
20
CA.SUB
14
C–DRIL
15
C–TAP
18
C–CYL.
Press the [18 C–CYL.] soft key to select cylindrical surface machining
around the C–axis, then specify the tool post, groove start point
X–coordinate, groove depth, and groove diameter.
Specifying these values automatically selects an end mill tool whose
length is greater than the groove depth and whose diameter is less than the
groove diameter, and determines the cutting conditions.
[18 C–CYL] (Machining type)
[HEAD–L] (Machining area)
100
INPUT (Groove start point X–coordinate)
10
INPUT (Groove depth)
10
INPUT (Groove diameter)
↓ (Cursor key)
↓ (Cursor key)
(2) Entering contour data (cylindrical surface machining around the
C–axis)
Pressing the cursor–down key (↓) at the end of the operations (1)
displays an entry window for the start point of contour data. Enter
the contour data according to the design drawings.
20 INPUT (Machining start point C–coordinate
50
INPUT (Machining start point Z–coordinate
[INSERT]
[ ] (Figure pattern)
INPUT
INPUT
180
INPUT (Center angle)
60
INPUT (C–coordinate for the center of an arc)
50
INPUT (Z–coordinate for the center of an arc)
[INSERT]
3.3.5
Specifying Process 3
(Cylindrical Surface
Machining Around the
C–axis)
Previous page
Next page
