FANUC SUPER CAP T / CAP II T Operators manual Page 578

Operators manual
B–62444E–1/04
A. PARAMETERS
APPENDIX
571
9833 TRDMIN
TRDMIN Minimum depth (radius) of cut for threading
Setting range: 0 to 99999999 Increment: 0.001 mm
0.0001 inches
9834 TRDFNX
TRDFNX Finish allowance along the X axis for threading (diameter)
Setting range: 0 to 99999999 Increment: 0.001 mm
0.0001 inches
9835 TRDAGL
TRDAGL Threading tool angle to be set automatically
0: The thread angle of 60° is automatically set when a new threading
process is created
Value other than 0: The value is automatically specified as a thread
angle.
Setting range: 0 to 255 Increment: Degrees (angle)
9836 CMFONM
CMFONM M code for enabling chamfering in threading
Setting range: 0 to 999
9837 CMFOFM
CMFOFM M code for disabling chamfering in threading
Setting range : 0 to 999
9838 MTUNCF
MTUNCF Coefficient of thread height (metric thread, unified thread)
Setting range: 0 to 32767 Increment: 1/10000
9839 PTPFCF
PTPFCF Coefficient of thread height (PT thread, PF thread)
Setting range: 0 to 32767 Increment: 1/10000
