FANUC SUPER CAP T / CAP II T Operators manual Page 235

Operators manual
13. SETTING DATA
B–62444E–1/04
OPERATION
222
In drilling, entering one of the final processes automatically determines
the required pre–processes.
Pressing the [10] soft key ([9] soft key if the C–axis graphic conversation
function is not provided) on the tool data menu screen displays the
pre–tool list screen. Up to five pre–tools can be registered for each final
tool.
Example of operation to specify pre–tools)
651 INPUT (LAST TL)
701
INPUT (PRE–TOOL 1)
601
INPUT (PRE–TOOL 2)
[CAP. :HEAD–L]
<
*** PRE–TOOL LIST *** NO. 01
TOOL NO. TL NAME NOMIL–D
LAST TL 651#01 TAP(F) 20.000
PRE–TOOL 1 701#01 CNT.DR(F) 2.000
2 601#01 DRIL (F) 20.000
3
4
5
MENU
RETURN
SEARCH TOOL
LIST
101#L OUTTER T0505 RN 0.400 AC 90 AN 60 TW 20.000
102#R OUTTER T0101 RN 0.400 AC 90 AN 60 TW 20.000
103#R OUTTER T0202 RN 0.400 AC 90 AN 60 TW 20.000
251#L OUTR TH T0404 RN 0.000 AN 60 TW 40.000
252#R OUTR TH T0606 RN 0.000 AN 60 TW 40.000
To display the registered–tool directory screen, pressing the [TOOL
LIST] soft key.
To search the list of pre–tools for a pre–tool for which a tool management
number has been registered at the final tool column, enter the tool
management number with numeric keys and press the [SEARCH] soft
key.
13.3
PRE–TOOL LIST
